CONTROL ELEMENTS
Control keys
Using the Stand
Key Function
POWER On / Off
SETUP Settings for DVD or DVB-T
PLAY/PAUSE, |<<,
>>|, >>, <<
Navigationskreuz Play/Pause, Skip and Fast playback
Navigations cross in Setup
VOLUME + /- Lautstärkeregelung
P MENU TFT (Panel) Menü, inklusive Wechsel der
Sourcen
Control keys on the front side of the HSD 7580:
Notes:
1.
With the button P MENU you can change different settings of the
TFT panel and choose the source.
2. The sources are DVD, DVB-T and AUX.
If you want to use the stand of
the HSD 7580 than you should
extract the bracket on the rear
side of the device. Please refer
the picture.
Notes:
•
Do not extract or twisted
the bracket not more than
the resistance.
•
The maximum angle is
around 45 degree.
•
If you extract the bracket
more than 45 degree, it
could be damage.
