Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage 6.0 V
Output Current P
D
/(V
IN
– V
O
) —
Output Pin Voltage GND -0.3 to V
IN
+0.3V V
Lead Soldering Temperature 300, (5sec) °C
Maximum Junction Temperature 150 °C
Storage Temperature -65 to +150 °C
ESD Rating Class B —
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Junction Temperature -40 to +125
°C
Ambient Temperature -40 to +85
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance (Junction to Case) θ
JC
SOT23/
TSOT25
130
°C/W
SOT-89 45
SC70 TBD
Thermal Resistance (Junction to Ambient) θ
JA
SOT23/
TSOT25
250
SOT-89 160
SC70 300
Internal Power Dissipation (@T
A
= +25°C) P
D
SOT23/
TSOT25
400
mW
SOT-89 550
SC70 300
