PAM3108
Document number: DSxxxxx Rev. 1 - 0
3 of 11
www.diodes.com
October 2012
© Diodes Incorporated
PAM3108
A Product Line of
Diodes Incorporated
Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage VIN, CTRL 6.0 V
Output Current 1.5 A
Output Pin Voltage GND -0.3 to V
IN
+0.3 V
Lead Soldering Temperature 260, (5sec) °C
Storage Temperature -65 to +150 °C
ESD Rating Class B —
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Max. Supply Voltage 5.5 V
Junction Temperature -40 to +125
°C
Operation Temperature -40 to +85
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance Junction to Case) θ
JC
W-DFN3x3-10 8.5
°C/W
SOP-8(EP) 11
Thermal Resistance (Junction to Ambient) θ
JA
W-DFN3x3-10 60
SOP-8(EP) 90
Internal Power Dissipation (@T
A
= 25°C) P
D
W-DFN3x3-10 1600
mW
SOP-8(EP) 1100
