Absolute Maximum Ratings (@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may
affect device reliability. All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage V
IN
6 V
SW Pin Voltage -0.3 to (V
IN
+0.3) V
FB Pin Voltage -0.3 to (V
IN
+0.3) V
EN Pin Voltage -0.3 to +6.0 V
Maximum Junction Temperature 150 °C
Storage Temperature Range -65 to +150 °C
Soldering Temperature 300, 5sec °C
Recommended Operating Conditions (@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.7 to 5.5 V
Junction Temperature Range -40 to +125
°C
Ambient Temperature Range -40 to +85
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance (Junction to Ambient) θ
JA
PSOP-8 90
°C/W
Thermal Resistance (Junction to Case) θ
JC
PSOP-8 14
Internal Power Dissipation (@TA= 25°C) P
D
PSOP-8 1100 mW
