Absolute Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
These are stress ratings only and functional operation is not implied. Exposure to absolute maximum ratings for prolonged time periods may affect device reliability.
All voltages are with respect to ground.
Parameter Rating Unit
Input Voltage PV
IN
, V
IN
6 V
SW Pin Voltage -0.3 to (PV
IN
+0.3) V
FB Pin Voltage -0.3 to (V
IN
+0.3) V
EN Pin Voltage -0.3 to +6.0 V
Maximum Junction Temperature 150 °C
Storage Temperature Range -65 to +150 °C
Soldering Temperature 300, 5sec °C
Recommended Operating Conditions
(@T
A
= +25°C, unless otherwise specified.)
Parameter Rating Unit
Supply Voltage 2.7 to 5.5 V
Junction Temperature Range -40 to +125
°C
Ambient Temperature Range -40 to +85
Thermal Information
Parameter Symbol Package Max Unit
Thermal Resistance (Junction to Ambient) θ
JA
SOP-8EP 90
°C/W
DFN3x3-10 60
QFN3x3-16 35
Thermal Resistance (Junction to Case) θ
JC
SOP-8EP 11
DFN3x3-10 8.5
QFN3x3-16 11
