MMBT6427

NPN SURFACE MOUNT DARLINGTON TRANSISTOR

Features

Epitaxial Planar Die Construction

Ideal for Low Power Amplification and Switching

High Current Gain

Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 1 and 4)

Mechanical Data

Case: SOT-23

Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020D

Terminals: Solderable per MIL-STD-202, Method 208

Lead Free Plating (Matte Tin Finish annealed over Alloy
42 leadframe).

Terminal Connections: See Diagram

Marking (See Page 3): K1D

Ordering & Date Code Information: See Page 3

Weight: 0.008 grams (approximate)

SOT-23

Dim

Min

Max

A

0.37

0.51

B

1.20

1.40

C

2.30

2.50

D

0.89

1.03

E

0.45

0.60

G

1.78

2.05

H

2.80

3.00

J

0.013

0.10

K

0.903

1.10

L

0.45

0.61

M

0.085

0.180

α

0

°

8

°

All Dimensions in mm

A

C

B

E

J

L

TOP VIEW

M

B

C

H

G

D

K

E

E

B

C

Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Collector-Base Voltage

V

CBO

40

V

Collector-Emitter Voltage

V

CEO

40

V

Emitter-Base Voltage

V

EBO

12

V

Collector Current - Continuous

I

C

500

mA

Thermal Characteristics

Characteristic

Symbol

Value

Unit

Power Dissipation (Note 2) @ T

A

= 25

°C P

D

300 mW

Thermal Resistance, Junction to Ambient (Note 2)@ T

A

= 25

°C

R

θJA

417

°C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +150

°C

Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Min

Max

Unit

Test Condition

OFF CHARACTERISTICS (Note 3)
Collector-Base Breakdown Voltage

V

(BR)CBO

40

V

I

C

= 100

μA, I

E

= 0

Collector-Emitter Breakdown Voltage

V

(BR)CEO

40

V

I

C

= 10mA, I

B

= 0

Emitter-Base Breakdown Voltage

V

(BR)EBO

12

V

I

E

= 10

μA, I

C

= 0

Collector Cutoff Current

I

CBO

50

nA

V

CB

= 30V, I

E

= 0

Collector Cutoff Current

I

CEO

1.0

μA

V

CE

= 25V, I

B

= 0

Emitter Cutoff Current

I

EBO

50

nA

V

EB

= 10V, I

C

= 0

ON CHARACTERISTICS (Note 3)

DC Current Gain

h

FE

10,000
20,000
14,000

100,000
200,000
140,000

I

C

= 10mA, V

CE

= 5.0V

I

C

= 100mA, V

CE

= 5.0V

I

C

= 500mA, V

CE

= 5.0V

Collector-Emitter Saturation Voltage

V

CE(SAT)

1.2
1.5

V

I

C

= 50mA, I

B

= 0.5mA

I

C

= 500mA, I

B

= 0.5mA

Base-Emitter Saturation Voltage

V

BE(SAT)

2.0

V

I

C

= 500mA, I

B

= 0.5mA

Base-Emitter On Voltage

V

BE(ON)

1.75

V

I

C

= 50mA, V

CE

=5.0V

SMALL SIGNAL CHARACTERISTICS
Output Capacitance

C

obo

8.0 Typical

pF

V

CB

= 10V, f = 1.0MHz, I

E

= 0

Input Capacitance

C

ibo

15 Typical

pF

V

EB

= 0.5V, f = 1.0MHz, I

C

= 0

Notes: 1. No purposefully added lead. Halogen and Antimony Free.

2. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout document AP02001, which

can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.

3. Short duration pulse test used to minimize self-heating effect.
4. Product manufactured with Data Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb

2

O

3

Fire Retardants.

DS30048 Rev. 9 - 2

1 of 3

www.diodes.com

MMBT6427

© Diodes Incorporated

Please click here to visit our online spice models database.
