ZXTR2005Z
Document number: DS36231 Rev. 3 - 2
4 of 7
December 2013
© Diodes Incorporated
ZXTR2005Z
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Output Voltage (Note 12)
V
OUT
4.5 5.0 5.5 V
V
IN
= 48V, I
OUT
= 15mA
Line Regulation (Notes 12 & 13)
V
OUT
— 195 300
mV
V
IN
= 10 to 72V, I
OUT
= 15mA
Temperature Coefficient
V
OUT
/
T
— 7.0 —
mV/°C
T
J
= -40°C to +125°C
V
IN
= 48V, I
OUT
= 15mA
Load Regulation (Notes 12 & 14)
V
OUT
—
-185
-205
-350
-400
mV
I
OUT
= 0.1 to 30mA, V
IN
= 48V
I
OUT
= 0.1 to 100mA, V
IN
= 48V
Minimum Value of Input Voltage Required to
Maintain Line Regulation
V
IN(MIN)
10 — — V
—
Quiescent Current
I
Q
—
—
260
550
500
900
µA
V
IN
= 48V, I
OUT
= 10µA
V
IN
= 100V, I
OUT
= 10µA
Power Supply Rejection Ratio
V
in
/
V
out
— 45 —
dB
C
OUT
= 100nF, I
OUT
= 15mA,
V
OUT
= 5V, V
IN
= 10 to 100V, f = 100Hz
Notes:
12. Measured under pulsed conditions. Pulse width ≤ 300μs. Duty cycle ≤ 2%.
13. Line regulation
V
OUT
= V
OUT
(@ V
IN
= 72V) – V
OUT
(@ V
IN
= 10V)
14. Load regulation
V
OUT
= V
OUT
(@ I
OUT
= 30mA) – V
OUT
(@ I
OUT
= 0.1mA)
V
OUT
= V
OUT
(@ I
OUT
= 100mA) – V
OUT
(@ I
OUT
= 0.1mA)
Typical Application Circuit
Pin Functions
Pin Name
Pin Function
Notes
V
IN
Input Supply
To maintain output regulation the input voltage can vary from 10V to 100V with respect to the GND pin. It is
recommended to connect a 1µF capacitor to GND.
GND
Power Ground
This pin should be tied to the system ground.
V
OUT
Voltage Output
Outputs a regulated 5V. It is recommended to connect a 10µF capacitor to GND. Minimum of 10µA must be
drawn from V
OUT
to maintain regulation. The pin can be pulled high to a maximum of 11V with respect to
ground.
