MJD340
Document number: DS31609 Rev. 2 - 2
3 of 4
www.diodes.com
December 2008
© Diodes Incorporated
MJD340
NEW PROD
UC
T
0.1 1 10 100
V , REVERSE VOLTAGE (V)
R
Fig. 7 Typical Capacitance Characteristics
1
10
100
1,000
C
A
P
A
C
IT
A
N
C
E (
p
F
)
C
ibo
C
obo
f = 1MHz
0.00001 0.0001 0.001 0.01 0.1 1 10 100 1,000
Fig. 8 Transient Thermal Response (Note 3)
t , PULSE DURATION TIME (s)
1
0.001
0.01
0.1
1
r(t),
T
R
ANSI
E
N
T
T
H
E
R
MA
L
R
ES
IS
T
AN
C
E
T - T = P * R (t)
Duty Cycle, D = t /t
J A JA
1 2
θ
R (t) = r(t) * θJA R
R = 81°C/W
θ
θ
JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
D = 0.5
Ordering Information
(Note 5)
Part Number Case Packaging
MJD340-13 DPAK 2500/Tape & Reel
Notes: 5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
MJD340 = Product Type Marking Code
= Manufacturers’ code marking
YYWW = Date Code Marking
YY = Last Digit of Year (ex: 08 = 2008)
WW = Week Code 01-52
YYWW
MJD340
