MMDT3906VC
www.diodes.com
Diodes Incorporated
•
Epitaxial Planar Die Construction
•
Ideal for Low Power Amplification and Switching
•
Ultra-Small Surface Mount Package
•
Lead Free By Design/RoHS Compliant (Note 1)
•
"Green" Device (Note 4)
Features
Maximum Ratings
@ T
A
= 25
°
C unless otherwise specified
A
M
L
B C
H
K
G
D
C
1
B
2
E
2
C
2
E
1
B
1
Mechanical Data
•
Case: SOT-563
•
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: See Diagram
•
Terminals: Finish - Matte Tin annealed over Copper
leadframe. Solderable per MIL-STD-202, Method 208
•
Marking & Type Code Information: See Last Page
•
Ordering Information: See Last Page
•
Weight: 0.003 grams (approximate)
MMDT3906VC
DUAL PNP SMALL SIGNAL SURFACE MOUNT
TRANSISTOR
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
-40
V
Collector-Emitter Voltage
V
CEO
-40
V
Emitter-Base Voltage
V
EBO
-5.0
V
Collector Current - Continuous
I
C
-200
mA
Power Dissipation (Note 3)
P
d
150
mW
Thermal Resistance, Junction to Ambient
R
θ
JA
833
°
C/W
Operating and Storage and Temperature Range
T
j
, T
STG
-55 to +150
°
C
SOT-563
Dim
Min
Max
Typ
A
0.15
0.30
0.25
B
1.10
1.25
1.20
C
1.55
1.70
1.60
D
0.50
G
0.90
1.10
1.00
H
1.50
1.70
1.60
K
0.56
0.60
0.60
L
0.10
0.30
0.20
M
0.10
0.18
All Dimensions in mm
SEE NOTE 2
C
1
B
2
E
2
C
2
E
1
B
1
T
C
U
D
O
R
P
W
E
N
Notes:
1. No purposefully added lead.
2. Package is non-polarized. Parts may be on reel in orientation illustrated, 180
°
rotated, or mixed (both ways).
3. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout
Thermal Characteristics
@ T
A
= 25
°
C unless otherwise specified
Characteristic
Symbol
Value
Unit
Power Dissipation (Note 3)
P
d
150
mW
Thermal Resistance, Junction to Ambient
R
θ
JA
833
°
C/W
