MMBD7000HS /HC
Document number: DS31782 Rev. 4 - 2
1 of 4
April 2010
© Diodes Incorporated
MMBD7000HS /HC
DUAL SURFACE MOUNT SWITCHING DIODE
Features
•
Fast Switching Speed
•
Surface Mount Package Ideally Suited for Automated Insertion
•
For General Purpose Switching Applications
• High
Conductance
•
Lead, Halogen and Antimony Free, RoHS Compliant (Note 3)
•
"Green" Device (Note 4)
Mechanical Data
• Case:
SOT-23
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminals: Matte Tin Finish annealed over Alloy 42 leadframe
(Lead Free Plating) Solderable per MIL-STD-202, Method 208
•
Polarity: See Diagram
•
Marking Information: See Page 2
•
Ordering Information: See Page 2
•
Weight: 0.008 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
100 V
RMS Reverse Voltage
V
R(RMS)
71 V
Forward Continuous Current (Note 1)
I
FM
300 mA
Non-Repetitive Peak Forward Surge Current
@ t = 1.0
μs
@ t = 1.0s
I
FSM
2.0
1.0
A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 1)
P
D
350 mW
Thermal Resistance Junction to Ambient Air (Note 1)
R
θJA
357
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Max
Unit
Test
Condition
Reverse Breakdown Voltage (Note 2)
V
(BR)R
100
⎯
V
I
R
= 100
μA
Forward Voltage
V
F
0.55
0.67
0.75
⎯
0.70
0.82
1.10
1.25
V
I
F
= 1.0mA
I
F
= 10mA
I
F
= 50mA
I
F
= 150mA
Reverse Current (Note 2)
I
R
⎯
1.0
3.0
100
25
μA
μA
μA
nA
V
R
= 50V
V
R
= 100V
V
R
= 50V, T
J
= 125
°C
V
R
= 20V
Total Capacitance
C
T
⎯
2.0 pF
V
R
= 0, f = 1.0MHz
Reverse Recovery Time
t
rr
⎯
4.0 ns
I
F
= I
R
= 10mA,
I
rr
= 0.1 x I
R
, R
L
= 100
Ω
Notes:
1. Part mounted on FR-4 board with recommended pad layout, which can be found on our website at
2. Short duration pulse test used to minimize self-heating effect.
3. No purposefully added lead. Halogen and Antimony Free.
4. Diodes Inc.'s "Green" policy can be found on our websit
TOP VIEW
SOT-23
MMBD7000HS
MMBD7000HC
