background image

MMBD4448V

Document number: DS30451 Rev. 7 - 2

1 of 2

www.diodes.com

March 2008

© Diodes Incorporated

MMBD4448V

SURFACE MOUNT FAST SWITCHING DIODE

Features

Ultra-Small Surface Mount Package

Fast Switching Speed

For General Purpose Switching Applications

High Conductance

Lead Free By Design/RoHS Compliant (Note 4)

"Green" Device (Note 5 and 6)

Mechanical Data

Case: SOT-563

Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020D

Terminals: Finish - Matte Tin annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208

Marking Information: See Page 2

Ordering Information: See Page 2

Weight: 0.003 grams (approximate)

SOT-563

Internal Schematic

C

1

A

1

NC

NC

A

2

C

2

TOP VIEW

BOTTOM VIEW

TOP VIEW

Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Non-Repetitive Peak Reverse Voltage

V

RM

100

V

Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage

V

RRM

V

RWM

V

R

80

V

RMS Reverse Voltage

V

R(RMS)

57

V

Forward Continuous Current (Note 2)

I

FM

500

mA

Average Rectified Output Current (Note 2)

I

O

250

mA

Non-Repetitive Peak Forward Surge Current

@ t = 1.0

μs

@ t = 1.0s

I

FSM

4.0
2.0

A

Thermal Characteristics

Characteristic

Symbol

Value

Unit

Power Dissipation (Note 2)

P

D

150

mW

Thermal Resistance Junction to Ambient (Note 2)

R

θJA

833

°C/W

Operating and Storage Temperature Range

T

J

, T

STG

-65 to +150

°C

Electrical Characteristics

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Min

Max

Unit

Test Condition

Reverse Breakdown Voltage (Note 3)

V

(BR)R

80

V

I

R

= 2.5

μA

Forward Voltage

V

F

0.62



0.72

0.855

1.0

1.25

V

I

F

= 5.0mA

I

F

= 10mA

I

F

= 100mA

I

F

= 150mA

Leakage Current (Note 3)

I

R

100

50
30
25

nA
μA
μA
nA

V

R

= 70V

V

R

= 75V, T

J

= 150

°C

V

R

= 25V, T

J

= 150

°C

V

R

= 20V

Total Capacitance

C

T

3.5

pF

V

R

= 6V, f = 1.0MHz

Reverse Recovery Time

t

rr

4.0

ns

V

R

= 6V, I

F

= 5mA

Notes:

1. Package is non-polarized. Parts may be on reel in orientation illustrated, 180° rotated, or mixed (both ways).
2. Device mounted on FR-4 PCB, 1 inch x 0.85 inch x 0.062 inch; pad layout as shown on Diodes Inc. suggested pad layout
document AP02001, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
3. Short duration pulse test used to minimize self-heating effect.
4. No purposefully added lead.

5. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.

6. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date

Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb

2

O

3

Fire Retardants.
