MMBD4448DW
Document number: DS31035 Rev. 12 - 2
3 of 4
www.diodes.com
February 2011
© Diodes Incorporated
MMBD4448DW
0.1
1
10
100
1,000
10,000
0 20 40 60 80 100
V , INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics, Per Element
R
I
, IN
S
T
AN
T
ANE
O
U
S
R
EV
E
R
SE
C
U
R
R
EN
T
(n
A
)
R
0
0.5
1
2.5
2
1.5
3
0 10 20 30 40
C
,
T
O
T
AL
C
A
P
A
C
IT
AN
C
E (
p
F
)
T
V ,DC REVERSE VOLTAGE (V)
Fig. 4 Total Capacitance vs. Reverse Voltage, Per Element
R
Package Outline Dimensions
Suggested Pad Layout
SOT-363
Dim Min Max
A 0.10 0.30
B 1.15 1.35
C 2.00 2.20
D 0.65 Typ
F 0.40 0.45
H 1.80 2.20
J 0 0.10
K 0.90 1.00
L 0.25 0.40
M 0.10 0.22
α 0° 8°
All Dimensions in mm
Dimensions Value (in mm)
Z 2.5
G 1.3
X 0.42
Y 0.6
C1 1.9
C2 0.65
A
M
J
L D
B C
H
K
F
X
Z
Y
C1
C2 C2
G
