Diodes MUR120 User Manual
Mur120, Mechanical data

DS30178 Rev. 3 - 2
1 of 3
MUR120
www.diodes.com
ã
Diodes Incorporated
MUR120
1.0A SUPER-FAST GLASS PASSIVATED RECTIFIER
Features
Maximum Ratings and Electrical Characteristics
@ T
A
= 25
°C unless otherwise specified
Mechanical Data
DO-41 Plastic
Dim
Min
Max
A
25.40
¾
B
4.06
5.21
C
0.71
0.864
D
2.00
2.72
All Dimensions in mm
Notes: 1. Measured at 1.0MHz and applied reverse voltage of 4V DC.
2. Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A. See Figure 6.
3. RoHS
·
Glass Passivated Die Construction
·
Super-Fast Recovery Time For High Efficiency
·
Low Forward Voltage Drop and High Current Capability
·
Surge Overload Rating to 35A Peak
·
Lead Free Finish, RoHS Compliant (Note 3)
·
Case: DO-41
·
Case Material: Molded Plastic
.
UL Flammability
Classification Rating 94V-0
·
Moisture Sensitivity: Level 1 per J-STD-020C
·
Terminals: Finish - Bright Tin. Solderable per
MIL-STD-202, Method 208
·
Polarity: Cathode Band
·
Ordering Information: See Last Page
·
Marking: R120
·
Weight: 0.34 grams (approximate)
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Characteristic
Symbol
Value
Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
V
RRM
V
RWM
V
R
200
V
RMS Reverse Voltage
V
R(RMS)
140
V
Average Rectified Output Current
@ T
L
= 130
°C
I
O
1.0
A
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
(JEDEC Method)
I
FSM
35
A
Forward Voltage @ I
F
= 1.0A, T
J
= 25°C
@ I
F
= 1.0A, T
J
= 150°C
V
FM
0.875
0.710
V
Peak Reverse Current
@ T
J
= 25
°C
at Rated DC Blocking Voltage
@ T
J
= 150
°C
I
RM
2.0
50
mA
Reverse Recovery Time (Note 2)
t
rr
25
ns
Typical Junction Capacitance (Note 1)
C
j
27
pF
Typical Thermal Resistance, Junction to Lead
R
qJL
50
K/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°C
