LM4041
PRECISION MICROPOWER SHUNT VOLTAGE REFERENCES
LM4041
Document number: DS32020 Rev. 8 - 2
2 of 7
www.diodes.com
September 2011
© Diodes Incorporated
Absolute Maximum Ratings
Description Rating Unit
Continuous Reverse Current (I
R
) 20 mA
Continuous Forward Current (I
F
) 10 mA
Maximum Output Voltage (LM4041_ADJ) 15 V
Junction Temperature -40 to 155 °C
Storage Temperature -55 to 150 °C
ESD Ratings
Human Body Model 4000 V
Machine Model 200 V
These are stress ratings only. Operation outside the absolute maximum ratings may cause device failure. Operation at the absolute
maximum rating, for extended periods may reduce device reliability.
Semiconductor devices are ESD sensitive and may be damaged by exposure to ESD events. Suitable ESD precautions should be taken
when handling and transporting these devices.
Package Thermal Data
Package θ
JA
P
DIS
T
A
= 25°C, T
J
= 150°C
SOT23 380°C/W 330mW
SC70-5 420°C/W 300mW
Recommended Operating Conditions
Parameter Min Max Units
Reverse Current 0.06 12 mA
Output Voltage Range 1.24 10 V
Operating Ambient Temperature Range -40 125
°C
