LMV331/ LMV393
Electrical Characteristics
(Notes 6 & 7) (@T
A
= +25°C, V
EE
= 0V, V
CM
= 0V and R
L
= 5.1KΩ
,
unless otherwise specified.)
Symbol
Parameter Test
Conditions
Min
Typ
Max
Unit
2.7V DC Electrical Characteristics
V
OS
Input Offset Voltage
1.7
7
mV
TCV
OS
Input Offset Voltage Average Drift
T
A
= full range
5
µV/°C
I
B
Input Bias Current
10
250
nA
T
A
= full range
400
I
OS
Input Offset Current
5
50
nA
T
A
= full range
150
V
CM
Common-Mode Input Voltage Range
-0.1
+2.0
V
V
SAT
Saturation Voltage
I
SINK
≤ 1mA
120 mV
I
O
Output Sink Current
V
O
≤ 1.5V
5 23 mA
I
OL
Output Leakage Current
0.003
µA
T
A
= full range
1
I
S
Supply Current
LMV331
40
100
µA
LMV393
(Both Comparators)
70
150
uA
2.7V AC Electrical Characteristics
t
PHL
Propagation delay high to low
Input
overdrive=
10mV
1000 ns
Input overdrive= 100mV
350
ns
t
PLH
Propagation delay low to high
Input overdrive= 10mV
500
ns
Input overdrive= 100mV
400
ns
5V DC Electrical Characteristics
V
OS
Input Offset Voltage
1.7
7
mV
T
A
= full range
9
TCV
OS
Input Offset Voltage Average Drift
T
A
= full range
5
µV/°C
I
B
Input Bias Current
25
250
nA
T
A
= full range
400
I
OS
Input Offset Current
2
50
nA
T
A
= full range
150
V
CM
Common-Mode Input Voltage Range
-0.1
4.2
V
A
V
Large Signal Differential Voltage Gain
20
50
V/mV
V
SAT
Saturation Voltage
I
SINK
≤ 4mA
200
400
mV
I
SINK
≤ 4mA, T
A
= full
range
700
I
O
Output Sink Current
V
O
≤ 1.5V
10 84 mA
I
OL
Output Leakage Current
0.003
µA
T
A
= full range
1
I
S
Supply Current
LMV331
60
120
µA
T
A
= full range
150
LMV393
(Both Comparators)
100
200
uA
T
A
=full range
250
5VAC Electrical Characteristics
t
PHL
Propagation delay high to low
Input overdrive = 10mV
600
ns
Input overdrive = 100mV
200
ns
t
PLH
Propagation delay low to high
Input overdrive = 10mV
450
ns
Input overdrive = 100mV
300
ns
Notes:
6. Typical values represent the most likely parametric norm as determined at the time of characterization. Actual typical values may vary over time and will
also depend on the application and configuration. The typical values are not tested and are not guaranteed on shipped production material.
7. All limits are guaranteed by testing or statistical analysis.
