DESD5V0S1BLP3
Document number: DS36257 Rev. 1 - 2
3 of 4
www.diodes.com
September 2013
© Diodes Incorporated
DESD5V0S1BLP3
NEW PROD
UC
T
NEW PROD
UC
T
0
t, TIME ( s)
Figure 3 Pulse Waveform

20 40 60
100
50
0
I
, PE
AK P
U
LS
E
C
URRENT
(
%
I
)
Pp
p
P C
, T
Y
PICAL
T
O
TA
L CAP
A
CI
TA
NCE
(
pF
)
J
V , REVERSE VOLTAGE (V)
Figure 4 Typical Capacitance
R
Characteristics
10
12
14
16
18
20
22
24
0 1 2 3 4 5 6
I
, L
E
AKA
G
E
C
U
R
R
EN
T
(n
A
)
R
V , REVERSE VOLTAGE (V)
Figure 5 Typical Reverse Characterisitcs
R
1000
0 1 2 3 4 5 6
100
10
1
T = -55°C
A
T = 85°C
A
T = 25°C
A
T = 150°C
A
T = 125°C
A
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
X3-DFN0603-2
Dim Min Max Typ
A 0.27 0.35 0.30
A1 0.00 0.03 0.02
b 0.19 0.29 0.24
D 0.595 0.645 0.62
E 0.295 0.345 0.32
e - - 0.355
L 0.14 0.24 0.19
All Dimensions in mm
L (2x)
E b (2x)
D
A1 (2x)
A
e
f = 1MHz
