SMAJ5.0(C)A – SMAJ200(C)A
Document number: DS19005 Rev. 16 - 2
2 of 5
January 2012
© Diodes Incorporated
SMAJ5.0(C)A – SMAJ200(C)A
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Part Number
Add C For
Bidirectional
(Note 7)
Reverse
Standoff
Voltage
Breakdown
Voltage
V
BR
@ I
T
(Note 8)
Test
Current
Max. Reverse
Leakage @ V
RWM
(Note 9)
Max. Clamping
Voltage @ I
pp
Max. Peak Pulse
Current
I
pp
Marking Code
V
RWM
(V)
Min (V) Max (V)
I
T
(mA) I
R
(
μA) V
C
(V)
(A) BI-
UNI-
SMAJ5.0(C)A 5.0 6.40
7.25
10
800
9.2
43.5
TE HE
SMAJ6.0(C)A 6.0 6.67
7.37
10
800
10.3
38.8
TG HG
SMAJ6.5(C)A 6.5 7.22
7.98
10
500
11.2
35.7
TK HK
SMAJ7.0(C)A 7.0 7.78
8.60
10
200
12.0
33.3
TM
HM
SMAJ7.5(C)A 7.5 8.33
9.21
1.0
100
12.9
31.0
TP HP
SMAJ8.0(C)A 8.0 8.89
9.83
1.0
50
13.6
29.4
TR HR
SMAJ8.5(C)A 8.5 9.44
10.4
1.0
10
14.4
27.7
TT HT
SMAJ9.0(C)A 9.0 10.0
11.1
1.0
5.0
15.4
26.0
TV HV
SMAJ10(C)A 10 11.1
12.3
1.0
5.0
17.0
23.5
TX
HX
SMAJ11(C)A 11 12.2
13.5
1.0
5.0
18.2
22.0
TZ
HZ
SMAJ12(C)A 12 13.3
14.7
1.0
5.0
19.9
20.1
UE IE
SMAJ13(C)A 13 14.4
15.9
1.0
5.0
21.5
18.6
UG
IG
SMAJ14(C)A 14 15.6
17.2
1.0
5.0
23.2
17.2
UK IK
SMAJ15(C)A 15 16.7
18.5
1.0
5.0
24.4
16.4
UM
IM
SMAJ16(C)A 16 17.8
19.7
1.0
5.0
26.0
15.3
UP IP
SMAJ17(C)A 17 18.9
20.9
1.0
5.0
27.6
14.5
UR
IR
SMAJ18(C)A 18 20.0
22.1
1.0
5.0
29.2
13.7
UT IT
SMAJ20(C)A 20 22.2
24.5
1.0
5.0
32.4
12.3
UV IV
SMAJ22(C)A 22 24.4
26.9
1.0
5.0
35.5
11.2
UX IX
SMAJ24(C)A 24 26.7
29.5
1.0
5.0
38.9
10.3
UZ IZ
SMAJ26(C)A 26 28.9
31.9
1.0
5.0
42.1
9.5
VE
JE
SMAJ28(C)A 28 31.1
34.4
1.0
5.0
45.4
8.8
VG
JG
SMAJ30(C)A 30 33.3
36.8
1.0
5.0
48.4
8.3
VK
JK
SMAJ33(C)A 33 36.7
40.6
1.0
5.0
53.3
7.5
VM
JM
SMAJ36(C)A 36 40.0
44.2
1.0
5.0
58.1
6.9
VP
JP
SMAJ40(C)A 40 44.4
49.1
1.0
5.0
64.5
6.2
VR
JR
SMAJ43(C)A 43 47.8
52.8
1.0
5.0
69.4
5.7
VT JT
SMAJ45(C)A 45 50.0
55.3
1.0
5.0
72.7
5.5
VV
JV
SMAJ48(C)A 48 53.3
58.9
1.0
5.0
77.4
5.2
VX
JX
SMAJ51(C)A 51 56.7
62.7
1.0
5.0
82.4
4.9
VZ JZ
SMAJ54(C)A 54 60.0
66.3
1.0
5.0
87.1
4.6
WE
RE
SMAJ58(C)A 58 64.4
71.2
1.0
5.0
93.6
4.3
WG
RG
SMAJ60(C)A 60 66.7
73.7
1.0
5.0
96.8
4.1
WK
RK
SMAJ64(C)A
64
71.1
78.6
1.0
5.0 103 3.9
WM
RM
SMAJ70(C)A
70
77.8
86.0
1.0
5.0 113 3.5
WP
RP
SMAJ75(C)A
75
83.3
92.1
1.0
5.0 121 3.3
WR
RR
SMAJ78(C)A
78
86.7
95.8
1.0
5.0 126 2.2
WT
RT
SMAJ85(C)A
85
94.4
104
1.0
5.0 137 2.9
WV
RV
SMAJ90(C)A
90
100
111
1.0
5.0 146 2.7
WX
RX
SMAJ100(C)A
100
111
123
1.0
5.0 162 2.5
WZ
RZ
SMAJ110(C)A
110
122
135
1.0
5.0 177 2.3
XE
SE
SMAJ120(C)A
120
133
147
1.0
5.0 193 2.0
XG
SG
SMAJ130(C)A
130
144
159
1.0
5.0 209 1.9
XK
SK
SMAJ150(C)A
150
167
185
1.0
5.0 243 1.6
XM
SM
SMAJ160(C)A
160
178
197
1.0
5.0 259 1.5
XP
SP
SMAJ170(C)A
170
189
209
1.0
5.0 275 1.4
XR
SR
SMAJ200(C)A
200
224
248
1.0
1.0 324 1.2
YT
ST
Notes:
7. Suffix C denotes Bi-directional device.
8. V
BR
measured with I
T
current pulse = 300
μs
9. For Bidirectional devices having V
RWM
of 10V and under, the I
R
is doubled.
