P6KE6V8(C)A - P6KE400(C)A

Document number: DS21502 Rev. 18 - 2

1 of 5

www.diodes.com

March 2010

© Diodes Incorporated

P6KE6V8(C)A - P6KE400(C)A


600W TRANSIENT VOLTAGE SUPPRESSOR

Features

600W Peak Pulse Power Dissipation

Voltage Range 6.8V - 400V

Constructed with Glass Passivated Die

Uni- and Bidirectional Versions Available

Excellent Clamping Capability

Fast Response Time

Lead Free Finish, RoHS Compliant (Note 1)

Mechanical Data

Case: DO-15

Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Leads: Plated Leads, Solderable per MIL-STD-202, Method 208

Marking: Unidirectional - Type Number and Cathode Band

Marking: Bidirectional - Type Number Only

Ordering Information: See Page 4

Weight: 0.4 grams (approximate)







Maximum Ratings

@T

A

= 25°C unless otherwise specified

Characteristic

Symbol

Value

Unit

Peak Power Dissipation, t

p

= 1.0 ms

(Non repetitive current pulse, derated above T

A

= 25°C)

P

pk

600 W

Peak Forward Surge Current, 8.3ms Single Half Sine Wave, Superimposed on Rated
Load Duty Cycle = 4 pulses per minute maximum

I

FSM

100 A

Forward Voltage @ I

F

= 35A



V

BR

≤ 200V

300µs Square Wave Pulse, Unidirectional Only



V

BR

> 200V

V

F

3.5
5.0

V

Thermal Characteristics

Characteristic

Symbol

Value

Unit

Steady State Power Dissipation at T

L

= 75°C

Lead Lengths 9.5 mm (Mounted on Copper Land Area of 40mm)

P

D

5.0 W

Typical Thermal Resistance, Junction to Case

R

θJC

20 °C/W

Typical Thermal Resistance, Junction to Lead

R

θJL

15 °C/W

Typical Thermal Resistance, Junction to Ambient

R

θJA

75 °C/W

Operating and Storage Temperature Range

T

J

, T

STG

-55 to +175

°C

Notes:

1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes.
