DMS3014SSS
NEW PROD
UC
T
N-CHANNEL ENHANCEMENT MODE MOSFET WITH SCHOTTKY DIODE
Features
•
DIOFET utilizes a unique patented process to monolithically
integrate a MOSFET and a Schottky in a single die to deliver:
• Low
R
DS(ON)
- minimizes conduction losses
• Low
V
SD
- reducing the losses due to body diode conduction
• Low
Q
rr
- lower Q
rr
of the integrated Schottky reduces body
diode switching losses
•
Low gate capacitance (Q
g
/Q
gs
) ratio – reduces risk of shoot-
through or cross conduction currents at high frequencies
•
Avalanche rugged – I
AR
and E
AR
rated
•
Lead Free, RoHS Compliant (Note 1)
•
"Green" Device (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
SO-8
•
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: See Diagram Below
•
Marking Information: See Page 5
•
Ordering Information: See Page 5
•
Weight: 0.072 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Drain-Source Voltage
V
DSS
30 V
Gate-Source Voltage
V
GSS
±12 V
Continuous Drain Current (Note 3) V
GS
= 4.5V
Steady
State
T
A
= 25°C
T
A
= 85°C
I
D
10.4
6.6
A
Pulsed Drain Current (Note 4)
I
DM
63 A
Avalanche Current (Notes 4 & 5)
I
AR
30 A
Repetitive Avalanche Energy (Notes 4 & 5) L = 0.1mH
E
AR
45 mJ
Thermal Characteristics
Characteristic Symbol
Value
Unit
Power Dissipation (Note 3)
P
D
1.55 W
Thermal Resistance, Junction to Ambient @T
A
= 25°C (Note 3)
R
θJA
81.3 °C/W
Operating and Storage Temperature Range
T
J
,
T
STG
-55 to +150
°C
Notes:
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our webs
4. Repetitive rating, pulse width limited by junction temperature.
5.
I
AR
and E
AR
rating are based on low frequency and duty cycles to keep T
J
= 25°C.
Top View
Top View
Internal Schematic
S
D
D
G
D
D
S
S
