DMC2700UDM
Datasheet Number: DS35360 Rev. 1 - 2
2 of 9
June 2011
© Diodes Incorporated
DMC2700UDM
NEW PROD
UC
T
A Product Line of
Diodes Incorporated
Maximum Ratings N-CHANNEL – Q
1
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Drain Source Voltage
V
DSS
20 V
Gate-Source Voltage
V
GSS
±6
V
Drain Current (Note 4)
T
A
= 25°C
T
A
= 85°C
I
D
1.34
0.97
A
Maximum Ratings P-CHANNEL – Q
2
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Drain Source Voltage
V
DSS
-20 V
Gate-Source Voltage
V
GSS
±6
V
Drain Current (Note 4)
T
A
= 25°C
T
A
= 85°C
I
D
-1.14
-1.07
A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Value
Unit
Power Dissipation (Note 4)
P
D
1.12 W
Thermal Resistance, Junction to Ambient (Note 4)
R
θJA
111
°C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
4. For a device mounted on 25mm X 25mm FR-4 PCB board with a high coverage of single sided 1oz copper, in still air conditions with two active die
