DMC2038LVT
Document number: DS35417 Rev. 6 - 2
3 of 10
September 2013
© Diodes Incorporated
DMC2038LVT
NEW PROD
UC
T
Electrical Characteristics N-CHANNEL – Q1
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
20
—
— V
V
GS
= 0V, I
D
= 250μA
Zero Gate Voltage Drain Current @T
c
= +25°C
I
DSS
— — 1.0
μA
V
DS
=16V, V
GS
= 0V
Gate-Source Leakage
I
GSS
— —
±100 nA
V
GS
= ±12V, V
DS
= 0V
ON CHARACTERISTICS (Note 7 )
Gate Threshold Voltage
V
GS(th)
0.4 — 1.0 V
V
DS
= V
GS
, I
D
= 250μA
Static Drain-Source On-Resistance
R
DS (ON)
—
27 35
mΩ
V
GS
= 4.5V, I
D
= 4.0A
—
33 43
V
GS
= 2.5V, I
D
= 2.5A
—
43 56
V
GS
= 1.8V, I
D
= 1.5A
Forward Transfer Admittance
|Y
fs
|
—
9 — S
V
DS
= 5V, I
D
= 3.4A
Diode Forward Voltage
V
SD
0.4 — 1.1 V
V
GS
= 0V, I
S
= 1A
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
—
400 530 pF
V
DS
= 10V, V
GS
= 0V,
f = 1.0MHz
Output Capacitance
C
oss
—
70 90 pF
Reverse Transfer Capacitance
C
rss
—
65 100 pF
Gate Resistance
R
g
—
1.9
—
Ω
V
DS
= 0V, V
GS
= 0V, f = 1MHz
Total Gate Charge (V
GS
= 4.5V)
Q
g
—
5.7
—
nC
V
DS
= 15V,I
D
= 5.8A
Total Gate Charge (V
GS
= 10V)
Q
g
—
12 17 nC
Gate-Source Charge
Q
gs
—
0.7
—
nC
Gate-Drain Charge
Q
gd
—
1.4
—
nC
Turn-On Delay Time
t
D(on)
—
5 10 ns
V
DS
= 10V, V
GS
= 4.5V,
R
G
= 6Ω, I
DS
= 1A,
Turn-On Rise Time
t
r
—
8 16 ns
Turn-Off Delay Time
t
D(off)
—
25 40 ns
Turn-Off Fall Time
t
f
—
8 16 ns
Notes: 7.
Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to product testing.
V , DRAIN -SOURCE VOLTAGE(V)
Fig. 1 Typical Output Characteristics
DS
I,
D
R
AI
N
C
U
R
R
EN
T
(A
)
D
0
5
10
15
20
25
30
0
0.5
1
1.5
2
V
=10V
GS
V
=4.5V
GS
V
=4.0V
GS
V
=3.5V
GS
V
=3.0V
GS
V
=2.5V
GS
V
=2.0V
GS
V
=1.5V
GS
V , GATE SOURCE VOLTAGE(V)
Fig. 2 Typical Transfer Characteristics
GS
I,
D
R
AI
N
C
U
R
R
EN
T
(A
)
D
0
5
10
15
20
0
0.5
1
1.5
2
2.5
3
T = 150 C
A
T = 125 C
A
T = 85 C
A
T = 25 C
A
T = -55 C
A
V
= 5.0V
DS
