background image

POWERDI is a registered trademark of Diodes Incorporated.

DMP4025SFG

Document Number: DS36107 Rev: 2 - 2

1 of 8

www.diodes.com

April 2013

© Diodes Incorporated

ADVAN

CE I

N

F

O

RM

ATI

O

N

A Product Line of

Diodes Incorporated

DMP4025SFG



40V P-CHANNEL ENHANCEMENT MODE MOSFET

POWERDI

®

Product Summary

V

(BR)DSS

R

DS(on)

max

I

D

max

T

A

= +25°C

(Notes 6)

-40V

25m

 @ V

GS

= -10V

- 7.2A

45m

 @ V

GS

= -4.5V

- 5.4A

Description

This MOSFET has been designed to minimize the on-state resistance
and yet maintain superior switching performance, making it ideal for
high efficiency power management applications.

Applications

 Motor

Control

 Backlighting
 DC-DC

Converters

 Printer

Equipment

Features

 Low

R

DS(on)

– Minimizes conduction losses

Fast switching speed – Minimizes switching losses

Totally Lead-Free & Fully RoHS compliant (Notes 1 & 2)

Halogen and Antimony Free. “Green” Device (Note 3)

Qualified to AEC-Q101 Standards for High Reliability

Mechanical Data

 Case:

POWERDI3333-8

Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals Connections: See diagram below

Terminals: Finish - Matte Tin annealed over Copper lead frame.
Solderable per MIL-STD-202, Method 208

Weight: 0.0172 grams (approximate)













Ordering Information

(Note 4)

Product

Marking

Reel Size (inches)

Tape Width (mm)

Quantity per Reel

DMP4025SFG-7 P40

7

8

2,000

DMP4025SFG-13 P40

13

8

3,000

Notes:

1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.

2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"

and Lead-free.

3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and

<1000ppm antimony compounds.
4. For packaging details, go to our website at http”//www.diodes.com/products/packages.html.


Marking Information








Top View

POWERDI3333-8

Device symbol

Bottom View

P40 = Product marking code
YYWW = Date Code Marking
YY = Year (ex: 12 = 2012)
WW = Week (01 - 53)

P40

YYW

W
