Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Units
Drain-Source Voltage V
DSS
-30 V
Gate-Source Voltage V
GSS
±20 V
Drain Current (Note 5) V
GS
= -10V
Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
-3.8
-2.9
A
Pulsed Drain Current (Note 6) I
DM
-11 A
Thermal Characteristics
Characteristic Symbol Value Units
Total Power Dissipation (Note 5) P
D
1.08 W
Thermal Resistance, Junction to Ambient @T
A
= +25°C (Note 5) R
θJA
115 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
-30 — — V V
GS
= 0V, I
D
= -250µA
Zero Gate Voltage Drain Current I
DSS
— — -800 nA V
DS
= -30V, V
GS
= 0V
Gate-Source Leakage I
GSS
— — ±100 nA V
GS
= ±20V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
-1.0 — -2.1 V V
DS
= V
GS
, I
D
= -250µA
Static Drain-Source On-Resistance R
DS(ON)
— —
65
99
mΩ
V
GS
= -10V, I
D
= -3.8A
V
GS
= -4.5V, I
D
= -3.0A
Forward Transfer Admittance |Y
fs
| — 3.6 — S V
DS
= -5V, I
D
= -2.7A
Diode Forward Voltage (Note 6) V
SD
— — -1.26 V V
GS
= 0V, I
S
= -2.7A
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
— 563 — pF
V
DS
= -25V, V
GS
= 0V,
f = 1.0MHz
Output Capacitance C
oss
— 48 — pF
Reverse Transfer Capacitance C
rss
— 41 — pF
Gate Resistance R
G
— 10.3 — Ω V
GS
= 0V V
DS
= 0V, f = 1MHz
SWITCHING CHARACTERISTICS (Note 8)
Total Gate Charge Q
g
— 5.2 —
nC
V
DS
= -15V, V
GS
= -4.5V,
I
D
= -3.8A
— 11 —
V
DS
= -15V, V
GS
= -10V,
I
D
= -3.8A
Gate-Source Charge Q
gs
— 1.7 —
Gate-Drain Charge Q
gd
— 1.9 —
Turn-On Delay Time t
d(on)
— 4.8 —
ns
V
DS
= -15V, V
GS
= -10V,
I
D
= -1A, R
G
= 6.0Ω
Rise Time t
r
— 5.0 —
Turn-Off Delay Time t
d(off)
— 31 —
Fall Time t
f
— 15 —
Notes: 5. Device mounted on FR-4 PCB on 2 oz., 0.5 in. 2 copper pads and t ≤5 sec.
6. Pulse width ≤10µS, Duty Cycle ≤1%.
7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to production testing.
