DMP3020LSS
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
-30 V
Gate-Source Voltage
V
GSS
25
V
Drain Current (Note 5) Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
-12
-6
A
Pulsed Drain Current (Note 6)
I
DM
-40 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Total Power Dissipation (Note 5)
P
D
2.5 W
Thermal Resistance, Junction to Ambient
R
JA
50 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
-30
V
V
GS
= 0V, I
D
= -250μA
Zero Gate Voltage Drain Current
I
DSS
-1
μA
V
DS
= -30V, V
GS
= 0V
Gate-Source Leakage
I
GSS
100
nA
V
GS
=
20V, V
DS
= 0V
800
V
GS
=
25V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
-1
-2 V
V
DS
= V
GS
, I
D
= -250μA
Static Drain-Source On-Resistance
R
DS (ON)
11.6
18.6
14
25
mΩ
V
GS
= -10V, I
D
= -8A
V
GS
= -4.5V, I
D
= -5A
Forward Transconductance
g
fs
12
S
V
DS
= -10V, I
D
= -12A
Diode Forward Voltage (Note 7)
V
SD
-0.5
-1.1 V
V
GS
= 0V, I
S
= -2A
DYNAMIC CHARACTERISTICS
Input Capacitance
C
iss
1802
pF
V
DS
= -15V, V
GS
= 0V, f = 1.0MHz
Output Capacitance
C
oss
415
pF
Reverse Transfer Capacitance
C
rss
295
pF
Gate Resistance
R
G
2.3
Ω
V
GS
= 0V, V
DS
= 0V, f = MHz
SWITCHING CHARACTERISTICS
Total Gate Charge
Q
g
15.3
30.7
nC
V
DS
= -15V, V
GS
= -4.5V, I
D
= -8A
V
DS
= -15V, V
GS
= -10V, I
D
= -8A
Gate-Source Charge
Q
gs
3.5
V
DS
= -15V, V
GS
= -10V, I
D
= -8A
Gate-Drain Charge
Q
gd
7.9
V
DS
= -15V, V
GS
= -10V, I
D
= -8A
Turn-On Delay Time
t
d(on)
5.1
ns
V
GS
= -10V, V
DS
= -15V,
R
D
= 15Ω, R
G
= 6Ω
Rise Time
t
r
8
Turn-Off Delay Time
t
d(off)
46
Fall Time
t
f
30
Notes:
5. Device mounted on 2 oz. Copper pads on FR-4 PCB with R
JA
= 50°C/W.
6. Pulse width
10μs, Duty Cycle 1%.
7. Short duration pulse test used to minimize self-heating effect.
