DMP3015LSS
Document number: DS31472 Rev. 6 - 2
2 of 5
October 2013
© Diodes Incorporated
DMP3015LSS
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
-30 V
Gate-Source Voltage
V
GSS
20
V
Drain Current (Note 5) Steady
State
T
A
= +25°C
T
A
= +70°C
I
D
-13
-9.75
A
Pulsed Drain Current (Note 6)
I
DM
-45 A
Thermal Characteristics
Characteristic Symbol
Value
Unit
Total Power Dissipation (Note 5)
P
D
2.5 W
Thermal Resistance, Junction to Ambient
R
JA
50 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Notes:
5. Device mounted on 2 oz. Copper pads on FR-4 PCB with R
JA
= 50°C/W.
6. Pulse width
10μS, Duty Cycle 1%.
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
-30
V
V
GS
= 0V, I
D
= -250μA
Zero Gate Voltage Drain Current
I
DSS
-1
A
V
DS
= -30V, V
GS
= 0V
Gate-Source Leakage
I
GSS
100
nA
V
GS
=
20V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
-1
-2 V
V
DS
= V
GS
, I
D
= -250μA
Static Drain-Source On-Resistance
R
DS (ON)
9
14
11
17
mΩ
V
GS
= -10V, I
D
= -13A
V
GS
= -4.5V, I
D
= -10A
Forward Transconductance
g
fs
15
S
V
DS
= -15V, I
D
= -8A
Diode Forward Voltage (Note 7)
V
SD
-0.5
-1.1 V
V
GS
= 0V, I
S
= -2.1A
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
2748
pF
V
DS
= -20V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
357
pF
Reverse Transfer Capacitance
C
rss
356
pF
Gate Resistance
R
G
2.0
Ω
V
DS
= 0V, V
GS
= 0V
f = 1.0MHz
SWITCHING CHARACTERISTICS (Note 8)
Total Gate Charge
Q
g
30.0
60.4
nC
V
DS
= -10V, V
GS
= -4.5V, I
D
= -13A
V
DS
= -10V, V
GS
= -10V, I
D
= -13A
Gate-Source Charge
Q
gs
7.2
V
DS
= -10V, V
GS
= -10V, I
D
= -13A
Gate-Drain Charge
Q
gd
16.4
V
DS
= -10V, V
GS
= -10V, I
D
= -13A
Turn-On Delay Time
t
d(on)
11.2
ns
V
DS
= -15V, V
GS
= -10V,
I
D
= -1A, R
G
= 6.0Ω
Rise Time
t
r
12.4
Turn-Off Delay Time
t
d(off)
104.9
Fall Time
t
f
61.7
Notes:
7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to product testing.
