DMG4413LSS
Document number: DS31754 Rev. 5 - 2
4 of 5
www.diodes.com
September 2013
© Diodes Incorporated
DMG4413LSS
NEW PROD
UC
T
Fig. 7 Gate Threshold Variation vs. Ambient Temperature
-50 -25 0 25 50 75 100 125 150
T , AMBIENT TEMPERATURE (°C)
A
0
0.3
0.6
0.9
1.2
1.5
1.8
2.1
2.4
2.7
3.0
-V
, G
A
T
E
T
H
R
ES
H
O
LD
V
O
LT
A
G
E (
V
)
GS
(T
H
)
I = -1mA
D
I = -250µA
D
0.2 0.4 0.6 0.8 1.0 1.2
Fig. 8 Diode Forward Voltage vs. Current
-V , SOURCE-DRAIN VOLTAGE (V)
SD
0
2
4
6
8
10
12
14
16
18
20
-I
, S
O
U
R
C
E
C
U
R
R
EN
T
(A
)
S
T = 25°C
A
0 5 10 15 20 25 30
Fig. 9 Typical Total Capacitance
-V , DRAIN-SOURCE VOLTAGE (V)
DS
100
1,000
10,000
C
,
C
A
P
A
C
IT
AN
C
E (
p
F
)
C
iss
C
rss
C
oss
f = 1MHz
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
SO-8
Dim Min Max
A - 1.75
A1 0.10 0.20
A2 1.30 1.50
A3 0.15 0.25
b 0.3 0.5
D 4.85 4.95
E 5.90 6.10
E1 3.85 3.95
e 1.27 Typ
h - 0.35
L 0.62 0.82
 0  8 
All Dimensions in mm
Gauge Plane
Seating Plane
Detail ‘A’
Detail ‘A’
E E1
h
L
D
e b
A2
A1
A
45 °
7 °~ 9 °
A3
0.
25
4
