DMP2104LP
NEW PROD
UC
T
P-CHANNEL ENHANCEMENT MODE FIELD EFFECT TRANSISTOR
Features
•
P-Channel MOSFET
•
Very Low On-Resistance
•
Very Low Gate Threshold Voltage
•
Low Input Capacitance
•
Fast Switching Speed
•
Low Input/Output Leakage
•
Ultra-Small Surface Mount Package
•
Lead Free By Design/RoHS Compliant (Note 2)
•
"Green" Device (Note 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
Case: DFN1411-3
•
Case Material: Molded Plastic, “Green” Molding
Compound. UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: See Diagram
•
Terminals: Finish - NiPdAu over Copper lead frame.
Solderable per MIL-STD-202, Method 208
•
Marking Information: See Page 3
•
Ordering Information: See Page 3
•
Weight: 0.003 grams (approximate)
DFN1411-3
D
S
G
TOP VIEW
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Internal Schematic
TOP VIEW
BOTTOM VIEW
Characteristic
Symbol
Value
Units
Drain-Source Voltage
V
DSS
-20
V
Gate-Source Voltage
V
GSS
±12 V
Continuous Drain Current (Note 1)
T
A
= 25°C
T
A
= 70°C
I
D
-1.5
-1.2
A
Thermal Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Units
Power Dissipation (Note 1)
P
D
500
mW
Thermal Resistance, Junction to Ambient (Note 1)
R
θJA
250
°C/W
Operating and Storage Temperature Range
T
j,
T
STG
-55 to +150
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
OFF CHARACTERISTICS (Note 4)
Drain-Source Breakdown Voltage
BV
DSS
-20
⎯
⎯
V
V
GS
= 0V, I
D
= -250
μA
Zero Gate Voltage Drain Current T
J
= 25
°C
T
J
= 125
°C
I
DSS
⎯
⎯
-1.0
-5.0
μA
V
DS
= -20V, V
GS
= 0V
Gate-Source Leakage
I
GSS
⎯
⎯
±100
nA
V
GS
=
±12V, V
DS
= 0V
ON CHARACTERISTICS (Note 4)
Gate Threshold Voltage
V
GS(th)
-0.45
⎯
-1.0 V
V
DS
= V
GS
, I
D
= -250
μA
V
GS
= -4.5V, I
D
= -950mA
V
GS
= -2.5V, I
D
= -670mA
Static Drain-Source On-Resistance
R
DS (ON)
⎯
92
134
180
150
200
240
m
Ω
V
GS
= -1.8V, I
D
= -200mA
Forward Transconductance
g
FS
⎯
3.1
⎯
S
V
DS
= -10V, I
D
= -810mA
Diode Forward Voltage (Note 4)
V
SD
⎯
⎯
-0.9 V
V
GS
= 0V, I
S
= -360mA
DYNAMIC CHARACTERISTICS
Input Capacitance
C
iss
⎯
320
⎯
pF
Output Capacitance
C
oss
⎯
80
⎯
pF
Reverse Transfer Capacitance
C
rss
⎯
60
⎯
pF
V
DS
= -16V, V
GS
= 0V
f = 1.0MHz
Notes:
1. Device mounted on FR-4 PCB with 1 inch square pads.
2. No purposefully added lead.
3. Diodes Inc.’s “Green” policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
4. Short duration pulse test used to minimize self-heating effect.
