DMN10H170SFG
Document number: DS36147 Rev. 4 - 2
2 of 6
August 2013
© Diodes Incorporated
DMN10H170SFG
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
100 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 6) V
GS
= 10V
Steady
State
T
A
= +25°C
T
A
= +70°C
T
C
= +25°C
I
D
2.9
2.4
8.5
A
t<10s
T
A
= +25°C
T
A
= +70°C
I
D
3.7
3.0
A
Maximum Continuous Body Diode Forward Current (Note 6)
I
S
3.0 A
Pulsed Drain Current (10µs pulse, duty cycle = 1%)
I
DM
16 A
Avalanche Current (Note 7)
I
AR
5.3 A
Avalanche Energy (Note 7)
E
AR
20 mJ
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Total Power Dissipation (Note 5)
T
A
= +25°C
P
D
0.94
W
T
A
= +70°C
0.6
Thermal Resistance, Junction to Ambient (Note 5)
Steady State
R
θJA
137 °C/W
t<10s 82
°C/W
Total Power Dissipation (Note 6)
T
A
= +25°C
P
D
2.0
W
T
A
= +70°C
1.3
Thermal Resistance, Junction to Ambient (Note 6)
Steady State
R
θJA
60 °C/W
t<10s 36
°C/W
Thermal Resistance, Junction to Case (Note 6)
R
θJC
7.0 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 8)
Drain-Source Breakdown Voltage
BV
DSS
100 — — V
V
GS
= 0V, I
D
= 250μA
Zero Gate Voltage Drain Current
I
DSS
— — 1.0
μA
V
DS
= 100V, V
GS
= 0V
Gate-Source Leakage
I
GSS
— —
±100 nA
V
GS
= ±20V, V
DS
= 0V
ON CHARACTERISTICS (Note 8)
Gate Threshold Voltage
V
GS(th)
1.0 — 3.0 V
V
DS
= V
GS
, I
D
= 250μA
Static Drain-Source On-Resistance
R
DS(ON)
—
99 122
mΩ
V
GS
= 10V, I
D
= 3.3A
—
104 133
V
GS
= 4.5V, I
D
= 3.0A
Forward Transfer Admittance
|Y
fs
|
—
4.4 — S
V
DS
= 10V, I
D
= 3.3A
Diode Forward Voltage
V
SD
—
0.7 1.0 V
V
GS
= 0V, I
S
= 3.3A
DYNAMIC CHARACTERISTICS (Note 9)
Input Capacitance
C
iss
—
870.7
—
pF
V
DS
= 25V, V
GS
= 0V,
f = 1.0MHz
Output Capacitance
C
oss
—
40.8
—
pF
Reverse Transfer Capacitance
C
rss
—
24.6
—
pF
Gate resistance
R
g
—
1.1
—
Ω
V
DS
= 0V, V
GS
= 0V, f = 1.0MHz
Total Gate Charge (V
GS
= 4.5V)
Q
g
—
7.0
—
nC
V
DS
= 50V, I
D
= 3.3A
Total Gate Charge (V
GS
= 10V)
Q
g
—
14.9
—
nC
Gate-Source Charge
Q
gs
— 3.3 — nC
Gate-Drain Charge
Q
gd
— 3.0 — nC
Turn-On Delay Time
t
D(on)
— 4.4 — ns
V
DD
= 50V, V
GEN
= 10V,
R
GEN
= 6.0Ω, I
D
= 3.3A
Turn-On Rise Time
t
r
— 2.3 — ns
Turn-Off Delay Time
t
D(off)
— 13.9 — ns
Turn-Off Fall Time
t
f
— 3.4 — ns
Reverse Recovery Time
t
rr
— 22.4 — ns
I
S
= 3.3A, dI/dt = 100A/μs
Reverse Recovery Charge
Q
rr
— 19.7 — nC
Notes:
5. Device mounted on FR-4 substrate PC board, 2oz copper, with minimum recommended pad layout.
6. Device mounted on FR-4 substrate PC board, 2oz copper, with 1inch square copper plate.
7. UIS in production with L = 1.43mH, T
J
= +25°C.
8. Short duration pulse test used to minimize self-heating effect.
9. Guaranteed by design. Not subject to product testing.
