POWERDI is a registered trademark of Diodes Incorporated
DMN10H120SFG
Document number: DS36250 Rev. 1 - 2
5 of 6
www.diodes.com
December 2013
© Diodes Incorporated
DMN10H120SFG
ADVAN
CE I
N
F
O
RM
ATI
O
N
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
0.001
0.01
0.1
1
10
100
0.1 1 10 100 1000
R
Limited
DS(on)
DC
P = 10s
W
P = 1s
W
P = 100ms
W
P = 10ms
W
P = 1ms
W
P = 100µs
W
-V , DRAIN-SOURCE VOLTAGE (V)
Figure 13 SOA, Safe Operation Area
DS
-I
, D
R
AI
N
C
U
R
R
E
N
T
(A
)
D
T = 150°C
T = 60°C
J(max)
A
Single Pulse
DUT on 1 * MRP Board
P = 60ms
W
P = 20ms
W
0.001
0.01
0.1
1
0.00001 0.0001 0.001 0.01 0.1 1 10 100 1000
t1, PULSE DURATION TIME (sec)
Figure 14 Transient Thermal Resistance
r(t),
T
R
ANSI
E
N
T
T
H
E
R
MA
L
R
ESI
S
TAN
C
E
D = 0.5
D = 0.7
D = 0.9
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
R (t) = r(t) * R
R = 52°C/W
Duty Cycle, D = t1/ t2
 

JA JA
JA
POWERDI3333-8
Dim Min Max Typ
D 3.25 3.35 3.30
E 3.25 3.35 3.30
D2 2.22 2.32 2.27
E2 1.56 1.66 1.61
A 0.75 0.85 0.80
A1 0 0.05 0.02
A3   0.203
b 0.27 0.37 0.32
b2   0.20
L 0.35 0.45 0.40
L1   0.39
e   0.65
Z   0.515
All Dimensions in mm
A
A1
A3
D
D2
E
E2
b2
(4x)
L
(4x)
L1
(3x)
b (8x) e Z (4x)
Pin 1 ID
1 4
8 5
