DMN5L06WK
Document number: DS30928 Rev. 8 - 2
2 of 6
March 2014
© Diodes Incorporated
DMN5L06WK
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Drain Source Voltage
V
DSS
50
V
Gate-Source Voltage
V
GSS
20
V
Drain Current (Note 5)
Continuous
Pulsed (Note 6)
I
D
300
800
mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Value
Unit
Total Power Dissipation (Note 5)
P
D
250
mW
Thermal Resistance, Junction to Ambient
R
θJA
500
C/W
Operating and Storage Temperature Range
T
J
, T
STG
-65 to +150
C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
50
V
V
GS
= 0V, I
D
= 10μA
Zero Gate Voltage Drain Current
@T
C
= +25°C
I
DSS
60
nA
V
DS
= 50V, V
GS
= 0V
Gate-Body Leakage
I
GSS
1
500
50
μA
nA
nA
V
GS
= ±12V, V
DS
= 0V
V
GS
= ±10V, V
DS
= 0V
V
GS
= ±5V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
0.49
1.0
V
V
DS
= V
GS
, I
D
= 250μA
Static Drain-Source On-Resistance
R
DS (ON)
3.0
2.5
2.0
Ω
V
GS
= 1.8V, I
D
= 50mA
V
GS
= 2.5V, I
D
= 50mA
V
GS
= 5.0V, I
D
= 50mA
On-State Drain Current
I
D(ON)
0.5
1.4
A
V
GS
= 10V, V
DS
= 7.5V
Forward Transconductance
|Y
fs
|
200
mS
V
DS
=10V, I
D
= 0.2A
Source-Drain Diode Forward Voltage
V
SD
0.5
1.4 V
V
GS
= 0V, I
S
= 115mA
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
50
pF
V
DS
= 25V, V
GS
= 0V
f = 1.0MHz
Output Capacitance
C
oss
25
pF
Reverse Transfer Capacitance
C
rss
5.0
pF
Turn-On Delay Time
t
D(on)
2.1
ns
V
DD
= 30V, V
GS
= 10V,
R
G
= 25Ω, I
D
= 200mA
Turn-On Rise Time
t
r
1.8
ns
Turn-Off Delay Time
t
D(off)
14.4
ns
Turn-Off Fall Time
t
f
8.4
ns
Notes:
5. Device mounted on FR-4 PCB.
6.
Pulse
width
10μS, Duty Cycle 1%.
7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to production testing.
