DMN63D8LV
Document number: DS36022 Rev. 2 - 2
2 of 6
August 2012
© Diodes Incorporated
DMN63D8LV
NEW PROD
UC
T
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Drain-Source Voltage
V
DSS
30 V
Gate-Source Voltage
V
GSS
±20 V
Continuous Drain Current (Note 5)
V
GS
=10V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
260
200
mA
Continuous Drain Current (Note 5) V
GS
=
5V
Steady
State
T
A
= 25°C
T
A
= 70°C
I
D
220
160
mA
Pulsed Drain Current (10
μs pulse, duty cycle = 1%)
I
DM
800 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Units
Total Power Dissipation
(Note 5)
P
D
450 mW
Thermal Resistance, Junction to Ambient
(Note 5)
R
θJA
281 °C/W
Operating and Storage Temperature Range
T
J,
T
STG
-55 to 150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol Min Typ Max Unit
Test
Condition
OFF CHARACTERISTICS (Note 6)
Drain-Source Breakdown Voltage
BV
DSS
30
⎯
⎯
V
V
GS
= 0V,
I
D
= 250
μA
Zero Gate Voltage Drain Current
I
DSS
⎯
⎯
1.0 µA
V
DS
= 30V,
V
GS
= 0V
Gate-Body Leakage
I
GSS
⎯
⎯
±10.0
μA V
GS
=
±20V,
V
DS
= 0V
ON CHARACTERISTICS (Note 6)
Gate Threshold Voltage
V
GS(th)
0.8
⎯
1.5 V
V
DS
= V
GS
,
I
D
= 250
μA
Static Drain-Source On-Resistance
R
DS (ON)
⎯
⎯
2.8
Ω
V
GS
= 10.0V,
I
D
= 250mA
⎯
⎯
3.8
V
GS
= 5.0V,
I
D
= 250mA
⎯
⎯
4.2
V
GS
= 4.5V,
I
D
= 250mA
⎯
⎯
4.5
V
GS
= 4.0V,
I
D
= 250mA
⎯
⎯
13
V
GS
= 2.5V,
I
D
= 10mA
Forward Transconductance
g
FS
80
⎯
⎯
mS V
DS
= 10V,
I
D
= 0.115A
Diode Forward Voltage
V
SD
- 0.8
1.2
V
V
GS
= 0V, I
S
= 115mA
DYNAMIC CHARACTERISTICS (Note 7)
Input Capacitance
C
iss
⎯
22.0
⎯
pF
V
DS
= 25V,
V
GS
= 0V,
f = 1.0MHz
Output Capacitance
C
oss
⎯
3.2
⎯
Reverse Transfer Capacitance
C
rss
⎯
2.0
⎯
Gate Resistance
R
G
⎯
79.9
⎯
Ω
V
DS
= 0V, V
GS
= 0V, f = 1.0MHz
Total Gate Charge V
GS
= 10V
Q
g
⎯
0.87
⎯
nC
V
GS
= 10V, V
DS
= 30V,
I
D
= 150mA
Total Gate Charge V
GS
= 4.5V
Q
g
⎯
0.43
⎯
Gate-Source Charge
Q
gs
⎯
0.11
⎯
Gate-Drain Charge
Q
gd
⎯
0.11
⎯
Turn-On Delay Time
t
D(on)
⎯
3.3
⎯
nS
V
DD
= 30V, I
D
= 0.115A,
V
GEN
= 10V
,
R
GEN
= 25
Ω
Turn-On Rise Time
t
r
⎯
3.2
⎯
Turn-Off Delay Time
t
D(off)
⎯
12.0
⎯
Turn-Off Fall Time
t
f
⎯
6.3
⎯
Notes:
5. Device mounted on FR-4 PC board, with minimum recommended pad layout, single sided.
6 .Short duration pulse test used to minimize self-heating effect.
7. Guaranteed by design. Not subject to production testing.
