DMN3112SSS
Document number: DS31582 Rev. 2 - 2
4 of 5
www.diodes.com
October 2013
© Diodes Incorporated
DMN3112SSS
Package Outline Dimensions
Please see AP02002 at http://www.diodes.com/datasheets/ap02002.pdf for latest version.
Fig. 9 Typical Total Capacitance
10
100
1,000
0 5 10 15 20 25 30
V , DRAIN-SOURCE VOLTAGE (V)
DS
C
, C
A
P
A
C
IT
AN
C
E (
pF
)
C
iss
C
oss
C
rss
r(t
),
T
R
A
N
S
IE
N
T
T
H
E
R
MA
L
R
ES
IS
TA
N
C
E
Fig. 10 Transient Thermal Response
t , PULSE DURATION TIME (s)
1
0.001
0.01
0.1
1
0.00001 0.0001 0.001 0.01 0.1 1 10 100 1,000
T - T = P * R (t)
Duty Cycle, D = t /t
J A JA
1 2

R (t) = r(t) * R
R = 168°C/W
 

JA JA
JA
P(pk)
t
1
t
2
D = 0.7
D = 0.5
D = 0.3
D = 0.1
D = 0.05
D = 0.02
D = 0.01
D = 0.005
D = Single Pulse
D = 0.9
SOP-8L
Dim Min Max
A - 1.75
A1 0.08 0.25
A2 1.40 1.50
A3 0.20 Typ
b 0.3 0.5
D 4.85 4.95
E 5.90 6.10
E1 3.80 3.90
e 1.27 Typ
h - 0.35
L 0.60 0.80
 0  8 
All Dimensions in mm
Gauge Plane
Seating Plane
Detail ‘A’
Detail ‘A’
E E1
h
L
D
e b
A2
A1
A
45 °
7 °~ 9 °
A3
0.
25
