Diodes DMN2500UFB4 User Manual
Product summary, Description and applications, Features and benefits
DMN2500UFB4
Document number: DS35724 Rev. 3 - 2
1 of 5
March 2012
© Diodes Incorporated
DMN2500UFB4
ADVAN
CE I
N
F
O
RM
ATI
O
N
N-CHANNEL ENHANCEMENT MODE MOSFET
Product Summary
V
(BR)DSS
R
DS(on) max
I
D
T
A
= 25°C
20V
0.4
Ω @ V
GS
= 4.5V
1A
0.7
Ω @ V
GS
= 1.8V
0.8A
Description and Applications
This new generation MOSFET has been designed to minimize the on-
state resistance (R
DS(on)
) and yet maintain superior switching
performance, making it ideal for high efficiency power management
applications.
• DC-DC
Converters
•
Power management functions
Features and Benefits
• Low
On-Resistance
•
Very Low Gate Threshold Voltage V
GS(TH)
, 1.0V max
•
Low Input Capacitance
•
Fast Switching Speed
•
Ultra-Small Surfaced Mount Package
•
Ultra-low package profile, 0.4mm maximum package height
•
ESD Protected Gate
•
Lead, Halogen, and Antimony Free, RoHS Compliant (Note 1)
•
"Green" Device (Note 2)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case:
X2-DFN1006-3
•
Case Material: Molded Plastic, “Green” Molding Compound. UL
Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020
•
Terminal Connections: See Diagram
•
Terminals: Finish – NiPdAu over Copper leadframe. Solderable
per MIL-STD-202, Method 208
•
Weight: 0.001 grams (approximate)
Ordering Information
(Note 3)
Part Number
Case
Packaging
DMN2500UFB4-7
X2-DFN1006-3
3,000/Tape & Reel
DMN2500UFB4-7B
X2-DFN1006-3
10,000/Tape & Reel
Notes:
1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. No purposely added lead. Halogen and Antimony free
2. Diodes Inc.’s “Green” policy can be found on our w
3. For packaging details, go to our website at
Marking Information
X2-DFN1006-3
Top View
Internal Schematic
Bottom View
NT = Product Type Marking Code
Top View
Bar Denotes Gate
and Source Side
D
S
G
ESD PROTECTED
Source
EQUIVALENT CIRCUIT
Gate
Protection
Diode
Gate
Drain
DMN2500UFB4-7
DMN2500UFB4-7B
Top View
Dot Denotes
Drain Side
NT
NT
