DMG1012UW
Document number: DS31859 Rev. 3 - 2
2 of 6
www.diodes.com
September 2013
© Diodes Incorporated
DMG1012UW
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Drain-Source Voltage V DSS
20 V
Gate-Source Voltage V
GSS
±6 V
Continuous Drain Current (Note 5)
Steady
State
T
A
= +25°C
T
A
= +85°C
I
D
1.0
0.64
A
Pulsed Drain Current (Note 6) I
DM
6 A
Thermal Characteristics
Characteristic Symbol Max Unit
Power Dissipation (Note 3) P
D
0.29 W
Thermal Resistance, Junction to Ambient @T
A
= +25°C (Note 3) R θJA 425 °C/W
Operating and Storage Temperature Range T
J , T
STG
-55 to +150 °C
Notes: 5. Device mounted on FR-4 PCB, with minimum recommended pad layout.
6. Repetitive rating, pulse width limited by junction temperature.
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
OFF CHARACTERISTICS (Note 7)
Drain-Source Breakdown Voltage
BV
DSS
20 - - V V
GS
= 0V, I
D
= 250μA
Zero Gate Voltage Drain Current T
J
= 25°C I
DSS
- - 100 nA V
DS
= 20V, V
GS
= 0V
Gate-Source Leakage I
GSS
- - ±1.0 μA
V
GS
= ±4.5V, V
DS
= 0V
ON CHARACTERISTICS (Note 7)
Gate Threshold Voltage
V
GS(th)
0.5 - 1.0 V V
DS
= V
GS
, I
D
= 250
μA
Static Drain-Source On-Resistance R
DS (ON)
-
0.3 0.45
Ω
V
GS
= 4.5V, I
D
= 600mA
0.4 0.6 V
GS
= 2.5V, I
D
= 500mA
0.5 0.75 V
GS
= 1.8V, I
D
= 350mA
Forward Transfer Admittance |Y
fs
| - 1.4 - S V
DS
= 10V, I
D
= 400mA
Diode Forward Voltage V
SD
- 0.7 1.2 V V
GS
= 0V, I
S
= 150mA
DYNAMIC CHARACTERISTICS (Note 8)
Input Capacitance
C
iss
- 60.67 - pF
V
DS
= 16V, V
GS
= 0V,
f = 1.0MHz
Output Capacitance C oss
- 9.68 - pF
Reverse Transfer Capacitance C
rss
- 5.37 - pF
Total Gate Charge Q
g
- 736.6 - pC
V
GS
= 4.5V, V
DS
= 10V,
I
D
= 250mA
Gate-Source Charge Q
gs
- 93.6 - pC
Gate-Drain Charge Q
gd
- 116.6 - pC
Turn-On Delay Time t
D(on)
- 5.1 - ns
V
DD
= 10V, V
GS
= 4.5V,
R
L
= 47
Ω, R
G
= 10
Ω,
I
D
= 200mA
Turn-On Rise Time t
r
- 7.4 - ns
Turn-Off Delay Time t D(off)
- 26.7 - ns
Turn-Off Fall Time t
f
- 12.3 - ns
Notes: 7. Short duration pulse test used to minimize self-heating effect.
8. Guaranteed by design. Not subject to production testing.
