DDTC (R1 = R2 SERIES) E
NPN PRE-BIASED SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
•
Epitaxial Planar Die Construction
•
Complementary PNP Types Available (DDTA)
•
Built-In Biasing Resistors, R1 = R2
•
Lead Free/RoHS Compliant (Note 1)
•
"Green" Device (Note 3 and 4)
Mechanical Data
•
Case: SOT-523
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: See Diagram
•
Terminals: Finish - Solderable per MIL-STD-202, Method
208
•
Lead Free Plating (Matte Tin Finish annealed over Alloy
42 leadframe).
•
Marking Information: See Table Below and Page 7
•
Ordering Information: See Page 7
•
Weight: 0.002 grams (approximate)
P/N
R1, RN (NOM)
Marking
DDTC123EE
DDTC143EE
DDTC114EE
DDTC124EE
DDTC144EE
DDTC115EE
2.2K
Ω
4.7K
Ω
10K
Ω
22K
Ω
47K
Ω
100K
Ω
N04
N08
N13
N17
N20
N24
A
M
J
L
D
B C
H
K
G
TOP VIEW
N
R1
OUT
B
C
E
R2
3
2
1
IN
GND(0)
SOT-523
Dim
Min
Max
Typ
A
0.15
0.30
0.22
B
0.75
0.85
0.80
C
1.45
1.75
1.60
D — —
0.50
G 0.90
1.10
1.00
H
1.50
1.70
1.60
J
0.00
0.10
0.05
K
0.60
0.80 0.75
L
0.10
0.30
0.22
M 0.10
0.20 0.12
N 0.45
0.65
0.50
α
0
°
8
°
—
All Dimensions in mm
1
3
2
GND (0)
C
B
IN
OUT
E
Equivalent Inverter Circuit
Schematic and Pin Configuration
Maximum Ratings
@T
A
= 25°C unless otherwise specified
DS30313 Rev. 9 - 2
1 of 6
www.diodes.com
DDTC (R1 = R2 SERIES) E
© Diodes Incorporated
Characteristic
Symbol
Value
Unit
Supply Voltage (3) to (2)
V
CC
50
V
Input Voltage (1) to (2)
DDTC123EE
DDTC143EE
DDTC114EE
DDTC124EE
DDTC144EE
DDTC115EE
V
IN
-10 to +12
-10 to +30
-10 to +40
-10 to +40
-10 to +40
-10 to +40
V
Output Current
DDTC123EE
DDTC143EE
DDTC114EE
DDTC124EE
DDTC144EE
DDTC115EE
I
O
100
100
50
30
100
20
mA
Power Dissipation
P
d
150
mW
Thermal Resistance, Junction to Ambient Air (Note 2)
R
θJA
833
°C/W
Operating and Storage Temperature Range
T
j,
T
STG
-55 to +150
°C
Notes:
1. No purposefully added lead.
2. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
3. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
4. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
