NPN PRE-BIASED SMALL SIGNAL SURFACE MOUNT TRANSISTOR
Features
•
Epitaxial Planar Die Construction
•
Complementary PNP Types Available (DDTA)
•
Built-In Biasing Resistors, R1
≠R2
•
Lead Free/RoHS Compliant (Note 1)
•
"Green" Device (Note 2 & 3)
Mechanical Data
DS30322 Rev. 9 - 2
1 of 4
www.diodes.com
DDTC (R1
≠R2 SERIES) UA
© Diodes Incorporated
•
Case: SOT-323
•
Case Material: Molded Plastic, "Green" Molding Compound,
Note 3. UL Flammability Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020C
•
Terminal Connections: See Diagram
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin Finish annealed over
Alloy 42 leadframe).
•
Marking Information: See Page 4
•
Type Code: See Table Below
•
Ordering Information: See Page 4
•
Weight: 0.006 grams (approximate)
P/N
R1 (NOM) R2 (NOM) Type Code
DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
1K
Ω
2.2K
Ω
2.2K
Ω
4.7K
Ω
4.7K
Ω
4.7K
Ω
10K
Ω
10K
Ω
22K
Ω
47K
Ω
47K
Ω
10K
Ω
10K
Ω
47K
Ω
10K
Ω
22K
Ω
47K
Ω
47K
Ω
4.7K
Ω
47K
Ω
10K
Ω
22K
Ω
N02
N05
N06
N09
N10
N11
N14
N15
N18
N21
N22
SOT-323
Dim
Min
Max
A
0.25
0.40
B
1.15
1.35
C
2.00
2.20
D
0.65 Nominal
E
0.30
0.40
G
1.20
1.40
H
1.80
2.20
J
0.0
0.10
K
0.90
1.00
L
0.25
0.40
A
M
J
L
E
D
C
B
M
0.10
0.18
α
0
°
8
°
All Dimensions in mm
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Supply Voltage, (3) to (2)
V
CC
50
V
Input Voltage, (1) to (2) DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
V
IN
-5 to +10
-5 to +12
-5 to +12
-7 to +20
-6 to +30
-5 to +30
-6 to +40
-10 to +30
-10 to +40
-15 to +40
-10 to +40
V
Output Current DDTC113ZUA
DDTC123YUA
DDTC123JUA
DDTC143XUA
DDTC143FUA
DDTC143ZUA
DDTC114YUA
DDTC114WUA
DDTC124XUA
DDTC144VUA
DDTC144WUA
I
O
100
100
100
100
100
100
70
100
50
30
30
mA
Output Current All
I
C
(Max)
100
mA
Notes:
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Product manufactured with Date Code 0627 (week 27, 2006) and newer are built with Green Molding Compound. Product manufactured prior to
Date Code 0627 are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
H
K
G
R1
OUT
B
C
E
R2
3
2
1
IN
GND(0)
1
3
2
GND (0)
C
B
IN
OUT
E
Schematic and Pin Configuration
Equivalent Inverter Circuit
