Diodes DDTA (R2-ONLY SERIES) CA User Manual
Ddta, R2-only series), Features

DDTA
(R2-ONLY SERIES)
CA
DS30336 Rev. 7 - 2
1 of 4
www.diodes.com
DDTA (R2-ONLY SERIES) CA
© Diodes Incorporated
PNP PRE-BIASED SMALL SIGNAL SOT-23
SURFACE MOUNT TRANSISTOR
Features
•
Epitaxial Planar Die Construction
•
Complementary NPN Types Available (DDTC)
•
Built-In Biasing Resistor, R2 only
•
Lead, Halogen and Antimony Free, RoHS Compliant
"Green" Device (Notes 2 and 3)
•
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
NEW PROD
U
C
T
•
Case: SOT-23
•
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
•
Moisture Sensitivity: Level 1 per J-STD-020D
•
Terminal Connections: See Diagram
•
Terminals: Solderable per MIL-STD-202, Method 208
•
Lead Free Plating (Matte Tin Finish annealed over Alloy
42 leadframe).
•
Marking: Date Code and Type Code: See Table Below &
Page 4
•
Ordering Information: See Page 4
•
Weight: 0.008 grams (approximate)
P/N
R2 (NOM)
Type Code
DDTA114GCA
DDTA124GCA
DDTA144GCA
DDTA115GCA
10K
Ω
22K
Ω
47K
Ω
100K
Ω
P26
P27
P28
P29
SOT-23
Dim
Min
Max
A
0.37
0.51
B
1.20
1.40
C
2.30
2.50
D
0.89
1.03
E
0.45
0.60
G
1.78
2.05
H
2.80
3.00
J
0.013
0.10
K
0.903
1.10
L
0.45
0.61
M
0.085
0.180
α
0
°
8
°
All Dimensions in mm
A
E
J
L
TOP VIEW
M
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Collector-Base Voltage
V
CBO
-50
V
Collector-Emitter Voltage
V
CEO
-50
V
Emitter-Base Voltage
V
EBO
-5
V
Collector Current
I
C
(Max)
-100
mA
Power Dissipation
P
D
200
mW
Thermal Resistance, Junction to Ambient Air (Note 1)
R
θJA
625
°C/W
Operating and Storage and Temperature Range
T
J
, T
STG
-55 to +150
°C
Notes:
1. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.
2. No purposefully added lead. Halogen and Antimony Free.
3. Product manufactured with Data Code V9 (week 33, 2008) and newer are built with Green Molding Compound. Product manufactured
prior to Date Code V9 are built with Non-Green Molding Compound and may contain Halogens or Sb
2
O
3
Fire Retardants.
B
R
2
SCHEMATIC DIAGRAM
E
C
B
C
H
G
D
K
C
B
E
