DDTA (R1 = R2 SERIES) UA
© Diodes Incorporated
Electrical Characteristics
@T A = 25°C unless otherwise specified
Characteristic Symbol Min Typ Max Unit Test Condition
V
l(off)
-0.5 -1.1 ⎯ V V
CC
= 5V, I
O
= 100
μA
Input Voltage
V
l(on)
⎯ -1.9 -3 V
V
O
= 0.3V, I
O
= 20mA, DDTA123EUA
V O = 0.3V, I O = 20mA, DDTA143EUA
V O = 0.3V, I O = 10mA, DDTA114EUA
V
O
= 0.3V, I
O
= 5mA, DDTA124EUA
V
O
= 0.3V, I
O
= 2mA, DDTA144EUA
V
O
= 0.3V, I
O
= 1mA, DDTA115EUA
Output Voltage V
O(on)
⎯ -0.1 -0.3 V
I
O
/I
l
=10mA/0.5mA, DDTA123EUA
I
O
/I
l
=10mA/0.5mA, DDTA143EUA
I
O
/I
l
=10mA/0.5mA, DDTA114EUA
I
O
/I
l
=10mA/0.5mA, DDTA124EUA
I
O
/I
l
=10mA/0.5mA, DDTA144EUA
I O /I l =5mA/0.25mA, DDTA115EUA
Input Current
DDTA123EUA
DDTA143EUA
DDTA114EUA
DDTA124EUA
DDTA144EUA
DDTA115EUA
I l
⎯ ⎯
-3.8
-1.8
-.88
-.36
-.18
-.15
mA V
I = -5V
Output Current I
O(off)
⎯ ⎯ 0.5
μA V
CC
= -50V, V
I
= 0V
DC Current Gain
DDTA123EUA
DDTA143EUA
DDTA114EUA
DDTA124EUA
DDTA144EUA
DDTA115EUA
G
l
-20
-20
-30
-56
-68
-82
⎯ ⎯ ⎯
V
O
= -5V, I
O
= -20mA
V
O
= -5V, I
O
= -10mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
V O = -5V, I O = -5mA
V
O
= -5V, I
O
= -5mA
Input Resistor (R
1
) Tolerance ΔR
1
-30 ⎯ +30 % ⎯
Resistance Ratio R
2
/R
1
0.8 1 1.2 ⎯ ⎯
Gain-Bandwidth Product* f
T
⎯ 250 ⎯ MHz
V
CE
= -10V, I
E
= 5mA,
f = 100MHz
* Transistor - For Reference Only
