DDTA (R1 = R2 SERIES) EE
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Supply Voltage
V
CC
50 V
Input Voltage
DDTA123EE
DDTA143EE
DDTA114EE
DDTA124EE
DDTA144EE
DDTA115EE
V
IN
+10 to -12
+10 to -30
+10 to -40
+10 to -40
+10 to -40
+10 to -40
V
Output Current
DDTA123EE
DDTA143EE
DDTA114EE
DDTA124EE
DDTA144EE
DDTA115EE
I
O
-100
-100
-50
-30
-30
-20
mA
Output Current
I
C
(Max)
-100 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Value
Unit
Power Dissipation (Note 5 & 6)
P
D
150 mW
Thermal Resistance, Junction to Ambient Air (Note 5)
R
θJA
833 °C/W
Operating and Storage Temperature Range
T
J
, T
STG
-55 to +150
°C
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Input Voltage
V
l(off)
-0.5
-1.1
V
V
CC
= -5V, I
O
= -100µA
V
l(on)
-1.9
-3
V
O
= -0.3V, I
O
= -20mA, DDTA123EE
V
O
= -0.3V, I
O
= -20mA, DDTA143EE
V
O
= -0.3V, I
O
= -10mA, DDTA114EE
V
O
= -0.3V, I
O
= -5mA, DDTA124EE
V
O
= -0.3V, I
O
= -2mA, DDTA144EE
V
O
= -0.3V, I
O
= -1mA, DDTA115EE
Output Voltage
V
O(on)
-0.1
-0.3
V
I
O
/I
l
= -10mA/-0.5mA DDTA123EE
I
O
/I
l
= -10mA/-0.5mA DDTA143EE
I
O
/I
l
= -10mA/-0.5mA DDTA114EE
I
O
/I
l
= -10mA/-0.5mA DDTA124EE
I
O
/I
l
= -10mA/-0.5mA DDTA144EE
I
O
/I
l
= -5mA/-0.25mA DDTA115EE
Input Current
DDTA123EE
DDTA143EE
DDTA114EE
DDTA124EE
DDTA144EE
DDTA115EE
I
l
-3.8
-1.8
-0.88
-0.36
-0.18
-0.15
mA
V
I
= -5V
Output Current
I
O(off)
-0.5
µA
V
CC
= -50V, V
I
= 0V
DC Current Gain
DDTA123EE
DDTA143EE
DDTA114EE
DDTA124EE
DDTA144EE
DDTA115EE
G
l
-20
-20
-30
-56
-68
-82
V
O
= -5V, I
O
= -20mA
V
O
= -5V, I
O
= -10mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
V
O
= -5V, I
O
= -5mA
Input Resistor Tolerance
R
1
-30
+30
%
Resistance Ratio Tolerance
R
2
/R
1
0.8
1
1.2
%
Gain-Bandwidth Product (Note 7)
f
T
250
MHz
V
CE
= -10V, I
E
= 5mA,
f = 100MHz
Notes:
5. Mounted on FR4 PC Board with minimum recommended pad layout.
6. 150mW per element must not be exceeded.
7. Transistor only.
