Page 2: Continued)
DS30326 Rev. 7 - 2
2 of 4
www.diodes.com
DDTA (R1
≠R2 SERIES) UA
© Diodes Incorporated
NEW PROD
UC
T
Maximum Ratings
(continued)
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Value
Unit
Output Current All
I
C
(Max)
-100
mA
Power Dissipation
P
d
200
mW
Thermal Resistance, Junction to Ambient Air (Note 4)
R
θJA
625
°C/W
Operating and Storage Temperature Range
T
j
, T
STG
-55 to +150
°C
Notes:
4. Mounted on FR4 PC Board with recommended pad layout as shown on Diodes Inc., suggested pad layout document AP02001, which can be found on
our website at http://www.diodes.com/datasheets/ap02001.pdf
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
DDTA113ZUA
DDTA123YUA
DDTA123JUA
DDTA143XUA
DDTA143FUA
DDTA143ZUA
DDTA114YUA
DDTA114WUA
DDTA124XUA
DDTA144VUA
DDTA144WUA
V
l(off)
-0.3
-0.3
-0.5
-0.3
-0.3
-0.5
-0.3
-0.8
-0.4
-1.0
-0.8
⎯
⎯
V
CC
= 5V, I
O
= 100
μA
Input Voltage DDTA113ZUA
DDTA123YUA
DDTA123JUA
DDTA143XUA
DDTA143FUA
DDTA143ZUA
DDTA114YUA
DDTA114WUA
DDTA124XUA
DDTA144VUA
DDTA144WUA
V
l(on)
⎯
⎯
-3.0
-3.0
-1.1
-2.5
-1.3
-1.3
-1.4
-3.0
-2.5
-5.0
-4.0
V
V
O
= -0.3V, I
O
= -20mA
V
O
= -0.3V, I
O
= -20mA
V
O
= -0.3V, I
O
= -5mA
V
O
= -0.3V, I
O
= -20mA
V
O
= -0.3V, I
O
= -3mA
V
O
= -0.3V, I
O
= -5mA
V
O
= -0.3V, I
O
= -1mA
V
O
= -0.3V, I
O
= -2mA
V
O
= -0.3V, I
O
= -2mA
V
O
= -0.3V, I
O
= -2mA
V
O
= -0.3V, I
O
= -2mA
Output Voltage
V
O(on)
⎯
-0.1
-0.3
V
I
O
/I
l
= -5mA/-0.25mA DDTA123JUA
I
O
/I
l
= -5mA/-0.25mA DDTA143ZUA
I
O
/I
l
= -5mA/-0.25mA DDTA114YUA
I
O
/I
l
= -10mA/-0.5mA All Others
Input Current
DDTA113ZUA
DDTA123YUA
DDTA123JUA
DDTA143XUA
DDTA143FUA
DDTA143ZUA
DDTA114YUA
DDTA114WUA
DDTA124XUA
DDTA144VUA
DDTA144WUA
I
l
⎯
⎯
-7.2
-3.8
-3.6
-1.8
-1.8
-1.8
-0.88
-0.88
-0.36
-0.16
-0.16
mA
V
I
= -5V
Output Current
I
O(off)
⎯
⎯
-0.5
μA
V
CC
= -50V, V
I
= 0V
DC Current Gain
DDTA113ZUA
DDTA123YUA
DDTA123JUA
DDTA143XUA
DDTA143FUA
DDTA143ZUA
DDTA114YUA
DDTA114WUA
DDTA124XUA
DDTA144VUA
DDTA144WUA
G
l
-33
-33
-80
-30
-68
-80
-68
-24
-68
-33
-56
⎯
⎯
⎯
V
O
= -5V, I
O
= -10mA
Input Resistor Tolerance
ΔR
1
-30
⎯
+30
%
⎯
Resistance Ratio Tolerance
ΔR
2
/R
1
-20
⎯
+20
%
⎯
Gain-Bandwidth Product*
f
T
⎯
250
⎯
MHz
V
CE
= -10V, I
E
= 5mA,
f = 100MHz
* Transistor - For Reference Only
