FMMT560Q
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-500
— — V
I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
-500
— — V
I
C
= -1mA
Emitter-Base Breakdown Voltage
BV
EBO
-7
— — V
I
E
= -100µA
Collector Cutoff Current
I
CBO
— — -100 nA
V
CB
= -500V
Emitter Cutoff Current
I
EBO
— — -100 nA
V
EB
= -5V
Static Forward Current Transfer Ratio (Note 9)
h
FE
100
80
—
—
—
15
300
300
—
—
I
C
= -1mA, V
CE
= -10V
I
C
= -50mA, V
CE
= -10V
I
C
= -100mA, V
CE
= -10V
Collector-Emitter Saturation Voltage (Note 9)
V
CE(sat)
—
—
-200
-500
mV
I
C
= - 20mA, I
B
= -2mA
I
C
= - 50mA, I
B
= -10mA
Base-Emitter Saturation Voltage (Note 9)
V
BE(sat)
—
—
-0.9 V
I
C
= -50mA, I
B
= -10mA
Base-Emitter Turn-On Voltage (Note 9)
V
BE(on)
— — -0.9 V
I
C
= -50mA, V
CE
= -10V
Output Capacitance
C
obo
— — 8 pF
V
CB
= -20V, f = 1MHz
Transition Frequency
f
T
60 — — MHz
V
CE
= -20V, I
C
= -10mA,
f = 50MHz
Turn-On Time
t
on
— 110 — ns V
CE
= -100V, I
C
= -50mA,
I
B1
= -5mA, I
B2
= 10mA
Turn-Off Time
t
off
— 1.5 — µs
Note: 9.
Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
