FMMT558
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
-400 V
Collector-Emitter Voltage V
CEO
-400 V
Emitter-Base Voltage V
EBO
-7 V
Continuous Collector Current I
C
-150 mA
Peak Pulse Current I
CM
-500 mA
Base Current I
B
-200 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P
D
500 mW
Thermal Resistance, Junction to Ambient (Note 6) R
θJA
250 °C/W
Thermal Resistance, Junction to Lead (Note 7) R
θJL
197 °C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 8)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM ≥ 8,000 V 3B
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 6. For a device surface mounted on 15mm X 15mm X 1.6mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions
7. Thermal resistance from junction to solder-point (at the end of the collector lead).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
