FMMT494
Document number: DS33095 Rev. 4 - 2
2 of 7
www.diodes.com
October 2012
© Diodes Incorporated
FMMT494
A Product Line of
Diodes Incorporated
Maximum Ratings
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Collector-Base Voltage V
CBO
140 V
Collector-Emitter Voltage V
CEO
120 V
Emitter-Base Voltage V EBO
7 V
Continuous Collector Current I
C
1 A
Peak Pulse Current I
CM
2 A
Base Current I
B
200 mA
Thermal Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Value Unit
Power Dissipation (Note 6) P
D
500 mW
Thermal Resistance, Junction to Ambient (Note 6) R θJA 250 °C/W
Thermal Resistance, Junction to Lead (Note 7) R θJL 197
°C/W
Operating and Storage Temperature Range T
J,
T
STG
-55 to +150 °C
ESD Ratings
(Note 8)
Characteristic Symbol Value Unit JEDEC Class
Electrostatic Discharge - Human Body Model ESD HBM 4,000 V 3A
Electrostatic Discharge - Machine Model ESD MM ≥ 400 V C
Notes: 6. For a device surface mounted on 15mm X 15mm FR4 PCB with high coverage of single sided 1 oz copper, in still air conditions; the device is measured
when operating in a steady-state condition.
7. Thermal resistance from junction to solder-point (at the end of the collector lead).
8. Refer to JEDEC specification JESD22-A114 and JESD22-A115.
