FCX555
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic
Symbol
Min
Typ
Max
Unit
Test Condition
Collector-Base Breakdown Voltage
BV
CBO
-180
—
—
V
I
C
= -100µA
Collector-Emitter Breakdown Voltage
BV
CEV
-180
—
—
V
I
C
= -1µA, -0.3V < V
BE
< 1V
Collector-Emitter Breakdown Voltage
BV
CER
-180
—
—
V
I
C
= -1µA, R
B
≤ 1kΩ
Collector-Emitter Breakdown Voltage (Note 10)
BV
CEO
-150
—
—
V
I
C
= -1mA
Emitter-Base Breakdown Voltage
BV
EBO
-7
-8.1
—
V
I
E
= -100µA
Collector Cutoff Current
I
CBO
—
—
<1
-
-20
-10
nA
µA
V
CB
= -144V
V
CB
= -144V, T
A
= +100°C
Emitter Cutoff Current
I
EBO
—
<1
-20
nA
V
EB
= -6V
DC current transfer Static ratio (Note 10)
h
FE
100
100
—
—
300
—
I
C
= -10mA, V
CE
= -5V
I
C
= -100mA, V
CE
= -5V
Collector-Emitter Saturation Voltage (Note 10)
V
CE(sat)
—
—
—
—
-300
-400
mV
I
C
= -100mA, I
B
= -10mA
I
C
= -250mA, I
B
= -25mA
Base-Emitter Saturation Voltage (Note 10)
V
BE(sat)
—
—
-1000
mV
I
C
= -250mA, I
B
= -25mA
Base-Emitter Turn-on Voltage (Note 10)
V
BE(on)
—
—
-950
mV
I
C
= -250mA, V
CE
= -5V
Transitional Frequency
f
T
—
100
—
MHz
I
E
= -50mA, V
CE
= -10V
f = 100MHz
Output capacitance
C
obo
—
—
10
pF
V
CB
= -10V, f = 1MHz,
Note:
10. Measured under pulsed conditions. Pulse width
≤ 300µs. Duty cycle ≤ 2%.
