Diodes DZT5401 - Manual (Page 3)

DS31218 Rev. 2 – 2 3 of 4
www.diodes.com
DZT5401
© Diodes Incorporated
0
10
20
30
40
50
60
70
0.01 0.1 1 10 100
V , REVERSE VOLTAGE (V)
R
Fig. 7 Typical Capacitance Characteristics
C
obo
C
ibo
f = 1MHz
0 20 40 60 80 1
-I , COLLECTOR CURRENT (mA)
C
f, 00
C
U
R
R
EN
T
G
AIN-
B
A
NDW
ID
T
H
P
R
O
D
U
C
T
(M
H
z)
T
Fig. 8 Typical Gain-Bandwidth Product vs. Collector Current
V = -10V
f = 100MHz
CE
NEW PROD
UC
T
Ordering Information
(Note 5)
Device Packaging Shipping
DZT5401-13 SOT-223 2500/Tape & Reel
Notes: 5. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Marking Information
YWW
(Top View)
K4M = Product type marking code
= Manufacturer’s code marking
YWW = Date code marking
Y = Last digit of year ex: 7 = 2007
WW = Week code 01 - 52
Package Outline Dimensions
SOT-223
Dim Min Max Typ
A 1.55 1.65 1.60
A1 0.010 0.15 0.05
b1 2.90 3.10 3.00
b2 0.60 0.80 0.70
C 0.20 0.30 0.25
D 6.45 6.55 6.50
E 3.45 3.55 3.50
E1 6.90 7.10 7.00
e — — 4.60
e1 — — 2.30
L 0.85 1.05 0.95
Q 0.84 0.94 0.89
All Dimensions in mm
