Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol
Min
Typ
Max Unit
Test
Condition
Collector-Base Breakdown Voltage
V
(BR)CBO
-180 -200
⎯
V
I
C
= -100
μA
Collector-Emitter Breakdown Voltage (Note 7)
V
(BR)CEO
-140 -160
⎯
V
I
C
= -10mA
Emitter-Base Breakdown Voltage
V
(BR)EBO
-7.0 -8.0
⎯
V
I
E
= -100
μA
Collector Cutoff Current
I
CBO
⎯
<1
⎯
-20
-0.5
nA
μA
V
CB
= -150V
V
CB
= -150V, T
amb
= 100 °C
Collector Cutoff Current
I
CER
R
≤1kΩ
⎯
<1
⎯
-20
-0.5
nA
μA
V
CB
= -150V
V
CB
= -150V, T
amb
= 100 °C
Emitter Cutoff Current
I
EBO
⎯
<1 -10 nA
V
EB
= -6V
Collector-Emitter Saturation Voltage (Note 7)
V
CE(sat)
⎯
-40
-55
-85
-275
-60
-80
-120
-360
mV
I
C
= -0.1A, I
B
= -5mA
I
C
= -0.5A, I
B
= -50mA
I
C
= -1A, I
B
= -100mA
I
C
= -3A, I
B
= -300mA
Base-Emitter Saturation Voltage (Note 7)
V
BE(sat)
⎯
-940 -1040 mV
I
C
= -3A, I
B
= -300mA
Base-Emitter Turn-On Voltage (Note 7)
V
BE(on)
⎯
-830 -930 mV
V
CE
= -5V, I
C
= -3A
DC Current Gain (Note 7)
h
FE
100
100
45
⎯
225
200
100
5
⎯
300
⎯
⎯
⎯
V
CE
= -5V, I
C
= -10mA
V
CE
= -5V, I
C
= -1A
V
CE
= -5V, I
C
= -3A
V
CE
= -5V, I
C
= -10A
Transition Frequency
f
T
⎯
120
⎯
MHz
V
CE
= -10V, I
C
= -100mA,
f = 50MHz
Output Capacitance
C
obo
⎯
33
⎯
pF
V
CB
= -10V, f = 1MHz
Switching Times
t
on
t
off
⎯
⎯
42
636
⎯
⎯
ns
ns
V
CC
= -50V, I
C
= 1A,
I
B1
= -I
B2
= -100mA
Notes:
7. Pulse Test: Pulse width
≤300μs. Duty cycle ≤2.0%.
