Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic Symbol Min Max Unit Test Condition
OFF CHARACTERISTICS (Note 5)
DS30624 Rev. 7 - 2 2 of 4
www.diodes.com
DP350T05
© Diodes Incorporated
Collector-Base Breakdown Voltage V
(BR)CBO
-350 ⎯ V I
C
= -100
μA, I
E
= 0
Collector-Emitter Breakdown Voltage V
(BR)CEO
-350 ⎯ V I
C
= -1.0mA, I
B
= 0
Emitter-Base Breakdown Voltage V (BR)EBO
-5.0 ⎯ V I E = -10
μA, I
C = 0
Collector Cutoff Current I CBO
⎯ -50 nA V CB = -200V, I E = 0
Collector Cutoff Current I EBO
⎯ -50 nA V CE = -3.0V, I C = 0
ON CHARACTERISTICS (Note 5)
DC Current Gain h
FE
20
30
30
20
15 ⎯
⎯
200
200
⎯
⎯
I
C
= -1.0mA, V
CE
= -10V
I C = -10mA, V CE = -10V
I
C
= -30mA, V
CE
= -10V
I
C
= -50mA, V
CE
= -10V
I
C
= -100mA, V
CE
= -10V
Collector-Emitter Saturation Voltage V
CE(SAT)
⎯
⎯
⎯
⎯
-0.30
-0.35
-0.50
-1.0
V
I
C
= -10mA, I
B
= -1.0mA
I
C
= -20mA, I
B
= -2.0mA
I
C
= -30mA, I
B
= -3.0mA
I
C
= -50mA, I
B
= -5.0mA
Base-Emitter Saturation Voltage V
BE(SAT)
⎯
⎯
⎯ -0.75
-0.85
-0.90
V
I
C
= -10mA, I
B
= -1.0mA
I
C
= -20mA, I
B
= -2.0mA
I C = -30mA, I B = -3.0mA
Base-Emitter On Voltage V
BE(ON)
⎯ -2.0 V I
C
= -100mA, V
CE
= -10V
SMALL SIGNAL CHARACTERISTICS
Output Capacitance
C
obo
⎯ 7.0 pF V
CB
= -20V, f = 1.0MHz, I
E
= 0
Transition Frequency f
T
50 ⎯ MHz V
CE
= -10V, I
C
= -20mA
Notes: 5. Short duration pulse test used to minimize self-heating effect.
0
50
100
25 50 75 100 125 150 175 200
P
,
P
O
WE
R
DIS
S
IP
A
T
IO
N (
m
W
)
D
T , AMBIENT TEMPERATURE (°C)
Fig. 1, Max Power Dissipation vs. Ambient Temperature
A
150
200
250
300
350
0 -1 -10 -100
I , COLLECTOR CURRENT (mA)
Fig. 2,
C
DC Current Gain vs. Collector Current
0
