Page 4
FMMT723
Document Number: DS33240 Rev. 4 - 2
4 of 7
January 2013
© Diodes Incorporated
A Product Line of
Diodes Incorporated
FMMT723
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
-100 -200 -
V I
C
= -100µA
Collector-Emitter Breakdown Voltage (Note 9)
BV
CEO
-100 -160 -
V I
C
= -10mA
Emitter-Base Breakdown Voltage
BV
EBO
-7 -8.8 -
V I
E
= -100µA
Collector Cutoff Current
I
CBO
- <1
-100 nA
V
CB
= -80V
Emitter Cutoff Current
I
EBO
- <1
-100 nA
V
EB
= -5.6V
Collector Emitter Cutoff Current
I
CES
- <1
-100 nA
V
CE
= -80V
Static Forward Current Transfer Ratio (Note 9)
h
FE
300 475 -
-
I
C
= -10mA, V
CE
= -10V
300 450 -
I
C
= -0.1A, V
CE
= -10V
250 375 -
I
C
= -0.5A, V
CE
= -10V
- 250 -
I
C
= -1A, V
CE
= -10V
- 30 -
I
C
= -1.5A, V
CE
= -10V
Collector-Emitter Saturation Voltage (Note 9)
V
CE(sat)
- -50
-80
mV
I
C
= - 0.1A, I
B
= -10mA
- -125
-200
I
C
= -0.5A, I
B
= -50mA
- -210
-330
I
C
= -1A, I
B
= -150mA
Base-Emitter Turn-On Voltage(Note 9)
V
BE(on)
- -0.71
-1.0 V I
C
= -1A, V
CE
= -10V
Base-Emitter Saturation Voltage(Note 9)
V
BE(sat)
- -0.89
-1.0 V I
C
= -1A, I
B
= -150mA
Output Capacitance
C
obo
- 13 20 pF
V
CB
= -10V, f = 1MHz
Transition Frequency
f
T
150 200 - MHz
V
CE
= -10V, I
C
= -50mA,
f = 100MHz
Turn-On Time
t
on
- 50 - ns
V
CC
= -50V, I
C
= -0.5A
I
B1
= I
B2
= -50mA
Turn-Off Time
t
off
- 760 - ns
Notes: 9.
Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%
