FMMT491
Document number: DS33091 Rev. 7 - 2
4 of 7
March 2014
© Diodes Incorporated
FMMT491
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol
Min
Typ
Max
Unit
Test
Condition
Collector-Base Breakdown Voltage
BV
CBO
80 — — V
I
C
= 100µA
Collector-Emitter Breakdown Voltage (Note 8)
BV
CEO
60 — — V
I
C
= 10mA
Emitter-Base Breakdown Voltage
BV
EBO
7 8.1 — V
I
E
= 100µA
Collector Cutoff Current
I
CBO
— <1 100 nA
V
CB
= 60V
Emitter Cutoff Current
I
EBO
— <1 100 nA
V
EB
= 5.6V
Collector Emitter Cutoff Current
I
CES
— <1 100 nA
V
CE
= 60V, V
CES
= 60V
Static Forward Current Transfer Ratio (Note 8)
h
FE
100 140 —
—
I
C
= 1mA, V
CE
= 5V
100 150 300
I
C
= 500mA, V
CE
= 5V
80 120 —
I
C
= 1A, V
CE
= 5V
30 40 —
I
C
= 2A, V
CE
= 5V
Collector-Emitter Saturation Voltage (Note 8)
V
CE(sat)
— 100 150
V
I
C
= 500mA, I
B
= 50mA
— 160 250
I
C
= 1A, I
B
= 100mA
Base-Emitter Turn-On Voltage(Note 8)
V
BE(on)
— 830
1000 mV
I
C
= 1A, V
CE
= 5V
Base-Emitter Saturation Voltage(Note 8)
V
BE(sat)
— 965
1100 mV
I
C
= 1A, I
B
= 100mA
Output Capacitance
C
obo
— — 10 pF
V
CB
= 10V, f = 1MHz
Transition Frequency
f
T
150 — — MHz
V
CE
= 10V, I
C
= 50mA,
f = 100MHz
Note:
8. Measured under pulsed conditions. Pulse width ≤ 300µs. Duty cycle ≤ 2%.
