FCX493A
A Product Line of
Diodes Incorporated
Electrical Characteristics
(@T
A
= +25°C, unless otherwise specified.)
Characteristic Symbol Min Typ Max Unit Test Condition
Collector-Base Breakdown Voltage BV
CBO
120 V I
C
= 100 µA
Collector-Emitter Breakdown Voltage (Note 10) BV
CEO
60 V I
C
= 10mA
Emitter-Base Breakdown Voltage BV
EBO
7 V I
E
= 100 µA
Collector-Base Cutoff Current I
CBO
100 nA V
CB
= 45V
Collector Cutoff Current I
CES
100 nA V
CES
= 45V
Emitter Cutoff Current I
EBO
100 nA V
EB
= 5V
Collector-Emitter Saturation Voltage (Note 10) V
CE(sat)
250
500
mV
I
C
= 500mA, I
B
= 50mA
I
C
= 1A, I
B
= 100mA
Base-Emitter Saturation Voltage (Note 10) V
BE(sat)
1.15 V I
C
= 1A, I
B
= 100mA
Base-Emitter Turn-On Voltage (Note 10) V
BE(on)
1.0 V I
C
= 1A, V
CE
= 10V
DC Current Gain (Note 10) h
FE
300
500
300
100
20
1200
I
C
= 1mA, V
CE
= 10V
I
C
= 150mA, V
CE
= 10V
I
C
= 250mA, V
CE
= 10V
I
C
= 500mA, V
CE
= 10V
I
C
= 1A, V
CE
= 10V
Transitional Frequency f
T
150 MHz
I
C
= 50mA, V
CE
= 10V
f=100MHz
Output capacitance C
obo
10 pF V
CB
= 10V, f=1MHz
Notes: 10. Measured under pulsed conditions. Pulse width ≤ 300 µs. Duty cycle ≤ 2%
